| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | PB4263 | ADAPTOR | 4 | ||||
| ? | WA3367 | NUT ASSM | 16 | ||||
| ? | EC7326 | TUBE, NYLON | 3 | ||||
| ? | PB4264 | BRACKET | 4 | ||||
| ? | TA0603 | FITTING, NYLON | 3 | ||||
| ? | TK1977 | GASKET | 3 | ||||
| ? | EC3858 | BAR, FLAT | 2 | ||||
| ? | VN9951 | LOCKNUT - 5/16" - 18NC | 4 | ||||
| ? | PB4255 | MODULE, SUPPRESSION | 8 | ||||
| ? | TG1929 | MACHINE SCREW - #10 - 24NC X 1/2" | 12 | ||||
| ? | SD4245 | LOCKWASHER - #10 (EXTERNAL TOOTH) | 14 | ||||
| ? | VC5344 | FLAT WASHER - #10 | 30 | ||||
| ? | DF0017 | NUT - #10 - 24NC | 16 | ||||
| ? | PB4265 | ADAPTOR | 4 | ||||
| ? | PB3506 | ADAPTOR | 2 | ||||
| ? | PB6200 | ADAPTOR | 2 | ||||
| ? | EC9124 | TUBE | 2 | ||||
| ? | TD1684 | NUT - 5/16" - 18NC | 2 | ||||
| ? | TA0602 | FITTING, NYLON | 1 | ||||
| ? | HC1580 | BUSHING, PIPE (1/4" X 1/8") | 1 |
