| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | MM0019 | CAPSCREW - M6 X 1.00 X 16 | 2 | ||||
| ? | MM0027 | CAPSCREW - M6 X 1.00 X 25 | 4 | ||||
| ? | MM0459 | FLAT WASHER - M6 | 10 | ||||
| ? | MM0469 | LOCKWASHER - M6 | 10 | ||||
| ? | MM0176 | NUT - M6 X 1.00 | 6 | ||||
| ? | PB1006 | LATCH/KEEPER SET | 1 | ||||
| ? | VZ2692 | LOCKNUT CONDULET | 1 | ||||
| ? | CH2156 | CABLE - 7J1LS | 1 | ||||
| ? | CH2155 | CABLE - 7J1RS | 1 | ||||
| ? | CH2153 | CABLE - 7J1R | 1 | ||||
| ? | CH2158 | CABLE - 7J7 | 1 | ||||
| ? | CH2159 | CABLE - 7J8 | 1 | ||||
| ? | EB9886 | STUD | 1 | ||||
| ? | ED8936 | CLEAT, CABLE | 4 | ||||
| ? | TN2590 | HOSE, SPACER | 4 | ||||
| ? | VA0609 | SPACER | 3 | ||||
| ? | ED8937 | CLEAT, CABLE | 6 | ||||
| ? | MM0464 | FLAT WASHER - M16 | 2 | ||||
| ? | MM0474 | LOCKWASHER - M16 | 2 | ||||
| ? | MM0181 | NUT - M16 | 2 | ||||
| ? | CH2522 | CABLE - 7J4 | 1 | ||||
| ? | CH2567 | CABLE - 74 | 1 | ||||
| ? | CH2157 | CABLE - 7J1 | 1 | ||||
| ? | TV1748 | CAPSCREW - 5/8" - 11NC X 1 1/2" | 1 | ||||
| ? | VC1390 | LOCKWASHER - 5/8" | 2 | ||||
| ? | TR9082 | FLAT WASHER - 5/8" | 2 | ||||
| ? | TV1749 | NUT - 5/8" - 11NC | 1 | ||||
| ? | CH2151 | CABLE - 7J2 | 1 | ||||
| ? | CH2164 | CABLE - 7GA1 (TO LEFT WHEEL MOTOR) | 1 | ||||
| ? | CH2154 | CABLE - 7J1L | 1 | ||||
| ? | CH2568 | CABLE - 71J | 1 | ||||
| ? | CH2570 | CABLE - 74AA | 1 | ||||
| ? | CH2571 | CABLE - 75XX | 1 | ||||
| ? | CH2566 | CABLE - 71G | 1 | ||||
| ? | CH2569 | CABLE - 74D | 1 | ||||
| ? | CH2524 | CABLE - 7J9 | 1 | ||||
| ? | VN9907 | CLAMP | 1 | ||||
| ? | EF8529 | HARNESS - GOV. POWER | 1 | ||||
| ? | EF8536 | HARNESS - GOV. BOX | 4 | ||||
| ? | 424243 | CLAMP | 4 | ||||
| ? | EF8534 | CABLE - GE FREQ. INPUT | 3 | ||||
| ? | TV3555 | PLUG, BUTTON | 1 | ||||
| ? | ED3913 | HARNESS | 1 | ||||
| ? | EC3638 | GASKET | 1 | ||||
| ? | EF4245 | COVER | 1 | ||||
| ? | TC6058 | CLAMP | 3 | ||||
| ? | EF2445 | HARNESS - OPERATOR CAB. | 1 | ||||
| ? | ED3408 | GASKET | 1 | ||||
| ? | EF8530 | PLATE | 1 | ||||
| ? | EF8537 | HARNESS - L.H. FRAME RAIL | 1 | ||||
| ? | EF8538 | HARNESS - R.H. FRAME RAIL | 2 | ||||
| ? | EF4244 | HARNESS, ACCUM. PRESS SW. | 1 | ||||
| ? | EC1090 | STUD, THREADED | 1 | ||||
| ? | C5769 | PLUG, PIPE | 1 | ||||
| ? | R2508 | TEE | 1 | ||||
| ? | TD9720 | ADAPTOR | 1 | ||||
| ? | VM4275 | HOSE | 1 | ||||
| ? | VY7326 | CONNECTOR, PIPE | 1 | ||||
| ? | EB6322 | BAR, BUS | 1 | ||||
| ? | VJ2296 | SHUNT | 2 | ||||
| ? | VM5737 | GRIP, CORD | 3 | ||||
| ? | HD7570 | PLUG, BUTTON | 1 | ||||
| ? | EC9112 | HARNESS - ERR | 1 | ||||
| ? | PB5372 | LOCKWASHER | 2 | ||||
| ? | PB5370 | NUT | 2 | ||||
| ? | EC9912 | HARNESS - 4-STEP | 1 |
