| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | VE3693 | • END CAP | 1 | ||||
| ? | VE3691 | • • HUB, FAN MOUNTING | 1 | ||||
| ? | VE3696 | • • RETAINER, SEAL (FRONT) (1) | 1 | ||||
| ? | VE4331 | • • SLEEVE, WEAR (FRONT) (1)/(2) | 1 | ||||
| ? | VE8124 | • • BEARING, MAIN (FRONT) (1) | 1 | ||||
| ? | VE1304 | • • PLATE, FACING | 7 | ||||
| ? | VE3690 | • • HUB, CLUTCH | 1 | ||||
| ? | VE4418 | • • SNAP RING, EXTERNAL | 1 | ||||
| ? | VE3692 | • • BEARING, SLEEVE (REAR) (1) | 1 | ||||
| ? | VE3692 | • • BEARING, SLEEVE (FRONT) (1) | 1 | ||||
| ? | VE3680 | • • OIL SEAL (FRONT) (1)/(2) | 1 | ||||
| ? | VE8524 | • • RETAINER, BEARING (FRONT) | 1 | ||||
| ? | VE3700 | • • O-RING SEAL (1)/(2) | 1 | ||||
| ? | VE8523 | • • BOLT | 8 | ||||
| ? | VE3684 | • • LOCKWASHER | 8 | ||||
| ? | VE1305 | • • CLUTCH PLATE, STEEL | 7 | ||||
| ? | VE3687 | • • PISTON | 1 | ||||
| ? | VE3688 | • • RING, SEAL (1)/(2) | 1 | ||||
| ? | VE8521 | • • PULLEY | 1 | ||||
| ? | VE3684 | • • LOCKWASHER | 8 | ||||
| ? | VE8523 | • • BOLT | 8 | ||||
| ? | VE3700 | • • O-RING SEAL (1)/(2) | 1 | ||||
| ? | VE8522 | • • RETAINER, BEARING (REAR) | 1 | ||||
| ? | VE3680 | • • OIL SEAL (REAR) (1)/(2) | 1 | ||||
| ? | VE3697 | • • SNAP RING, INTERNAL (1) | 1 | ||||
| ? | VE3689 | • • SEAL RING, SMALL (1)/(2) | 1 | ||||
| ? | VE3701 | • • SPRING WASHER (1)/(2) | 1 | ||||
| ? | VE3697 | • • SNAP RING, INTERNAL (1) | 1 | ||||
| ? | VE3702 | • • SNAP RING, EXTERNAL (1) | 1 | ||||
| ? | VE3703 | • • SHIM (1)/(2) | 1 | ||||
| ? | VE3678 | • • SHAFT & BRACKET ASSM | 1 | ||||
| ? | TH5103 | • • RING, SEAL (1)/(2) | 2 | ||||
| ? | VE3711 | • • PITOT TUBES (1)/(2) | 2 | ||||
| ? | VE3679 | • • SLEEVE, WEAR (REAR) (1)/(2) | 1 | ||||
| ? | VE1297 | • • FITTING, ORIFICE | 1 | ||||
| ? | VE3696 | • • RETAINER, SEAL (REAR) (1) | 1 | ||||
| ? | VE8124 | • • BEARING, MAIN (REAR) (1) | 1 | ||||
| ? | VE3686 | • • SNAP RING, EXTERNAL (1) | 1 | ||||
| ? | VS7811 | • • NAME PLATE KIT (1)/(2) | 1 | ||||
| ? | VS7810 | • • ADJUSTING BRACKET | 1 | ||||
| ? | VE3684 | • • LOCKWASHER | 4 | ||||
| ? | VE3695 | • • BOLT | 4 | ||||
| ? | VE3714 | • • ENGINE INTERCOOLER THERMO SENSOR (120 - 130 DEG) (3) | 1 | ||||
| ? | VE3715 | • • ENGINE JACKET COOLANT SENSOR (180 - 190 DEG) (3) | 1 | ||||
| ? | VE3742 | • • NOTE: (1) INCLUDED IN VE3742 OVERHAUL KIT. | 65535 | ||||
| ? | VE3741 | • • (2) INCLUDED IN VE3741 SEAL KIT. | 65535 | ||||
| ? | • • (3) NOT INCLUDED IN VE8512 | 65535 |
