| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | PB7130 | • GAUGE, SIGHT | 1 | ||||
| ? | CD9707 | • • CLAMP | 1 | ||||
| ? | ED2727 | • • BRACKET | 1 | ||||
| ? | TZ3542 | • • ELBOW | 1 | ||||
| ? | SF9435 | • • PLUG, PIPE MAGNETIC | 1 | ||||
| ? | TF6957 | • • COCK, DRAIN | 1 | ||||
| ? | E2579 | • • NIPPLE, CLOSE | 1 | ||||
| ? | DA5236 | • • HOSE | 1 | ||||
| ? | VP5644 | • • CLAMP, T-BOLT | 2 | ||||
| ? | EC8693 | • • GASKET | 1 | ||||
| ? | C1603 | • • CAPSCREW - 3/8" - 16NC X 1 1/4" | 4 | ||||
| ? | C0312 | • • LOCKWASHER - 3/8" | 5 | ||||
| ? | EC0364 | • • HOSE | 6 | ||||
| ? | WA1054 | • • CLAMP, T-BOLT | 12 | ||||
| ? | WA3038 | • • ADAPTOR, STRAIGHT | 1 | ||||
| ? | VN9907 | • • CLAMP | 4 | ||||
| ? | KC5053 | • • FITTING, TUBE | 1 | ||||
| ? | TA4493 | • • HOSE | 2 | ||||
| ? | HA1181 | • • HOSE | 1 | ||||
| ? | TF7161 | • • FLAT WASHER | 4 | ||||
| ? | VD6174 | • • CLAMP | 4 | ||||
| ? | EC9255 | • • TUBE - L.H. | 1 | ||||
| ? | EC9255 | • • TUBE - R.H. | 1 | ||||
| ? | EC8150 | • • TUBE - R.H. | 1 | ||||
| ? | EC9253 | • • TUBE - R.H. | 1 | ||||
| ? | EC9252 | • • TUBE - L.H. | 1 | ||||
| ? | EC8149 | • • TUBE - L.H. | 1 | ||||
| ? | R2028 | • • PLUG, PIPE | 2 | ||||
| ? | C5771 | • • PLUG | 3 | ||||
| ? | VN0823 | • • CLAMP, T-BOLT | 8 | ||||
| ? | EC0743 | • • HOSE | 4 | ||||
| ? | SG3435 | • • FITTING, PIPE | 1 | ||||
| ? | TD9743 | • • ADAPTOR | 1 | ||||
| ? | WA2237 | • • CLAMP | 1 | ||||
| ? | C1602 | • • CAPSCREW - 3/8" - 16NC X 1" | 1 | ||||
| ? | WA0720 | • • FLAT WASHER - 3/8" | 1 |
