| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | TY4907 | • CAP | 2 | ||||
| ? | C1669 | • • CAPSCREW - 1" - 8NC X 3 1/2" | 4 | ||||
| ? | C1544 | • • LOCKWASHER - 1" | 4 | ||||
| ? | TC8757 | • • BUSHING, PIPE | 1 | ||||
| ? | PB4928 | • • BREATHER | 1 | ||||
| ? | PB1760 | • • FUEL CAP ASSM (1) | 1 | ||||
| ? | D5576 | • • CAP, PIPE | 1 | ||||
| ? | TD9741 | • • FITTING, TUBE | 1 | ||||
| ? | HA0915 | • • HOSE | 1 | ||||
| ? | C1523 | • • NUT - 1/2" - 13NC | 4 | ||||
| ? | C1540 | • • LOCKWASHER - 1/2" | 4 | ||||
| ? | VN9999 | • • CLAMP | 4 | ||||
| ? | ED1366 | • • TUBE | 1 | ||||
| ? | HA0920 | • • HOSE | 1 | ||||
| ? | EG2752 | • • HARNESS, FUEL TANK | 1 | ||||
| ? | PB0707 | • • GAUGE, FUEL | 1 | ||||
| ? | VW1231 | • • GASKET | 1 | ||||
| ? | S5315 | • • CAPSCREW - 1/4" - 28NF X 3/4" (SOCKET HEAD) | 4 | ||||
| ? | CC6807 | • • LOCKWASHER - 1/4" (INTERNAL TOOTH) | 4 | ||||
| ? | PB8220 | • • TRANSMITTER, FUEL GAUGE | 1 | ||||
| ? | TY5209 | • • PLATE, COVER | 1 | ||||
| ? | VA1732 | • • GASKET | 1 | ||||
| ? | VN6448 | • • CAPSCREW - 5/16" - 18NC X 3/4" (NYLON) | 4 | ||||
| ? | C1538 | • • LOCKWASHER - 5/16" | 4 | ||||
| ? | TA1683 | • • COVER (1) | 1 | ||||
| ? | TA1687 | • • GASKET (1) | 1 | ||||
| ? | C0312 | • • LOCKWASHER - 3/8" (1) | 6 | ||||
| ? | VN6450 | • • CAPSCREW - 3/8" - 16NC X 7/8" (NYLON) | 6 | ||||
| ? | HC1851 | • • COCK, DRAIN | 1 | ||||
| ? | HD0876 | • • BUSHING, PIPE | 1 | ||||
| ? | HC4691 | • • PLUG, PIPE | 2 | ||||
| ? | EB8253 | • • TANK, FUEL | 1 | ||||
| ? | TF6990 | • • FITTING, TUBE | 1 | ||||
| ? | TG0545 | • • FLAT WASHER - 3/8" (COPPER) | 3 | ||||
| ? | TC1231 | • • LOCKWASHER - 3/8" | 3 | ||||
| ? | TG2562 | • • CLAMP | 2 | ||||
| ? | TC1233 | • • NUT - 3/8" - 16NC | 3 | ||||
| ? | TC1234 | • • CAPSCREW - 3/8" - 16NC X 3/4" | 3 | ||||
| ? | VL7792 | • • DAMPENER, RUBBER | 4 | ||||
| ? | VW6877 | • • FLAT WASHER | 4 | ||||
| ? | VN9179 | • • CAPSCREW - 3/4" 8NC X 6" | 4 | ||||
| ? | VL4462 | • • WIRE, GROUND | 1 | ||||
| ? | WA4730 | • • FLAT WASHER - 3/4" | 4 | ||||
| ? | C1542 | • • LOCKWASHER - 3/4" | 4 | ||||
| ? | • • NOTE: (1) IF EQPD W/QUICK FILL OPTION, REFER TO | 65535 | |||||
| ? | • • PRESSURE FUELING PG FOR THESE ITEMS | 65535 |
