| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | VM0065 | • RELAY | 2 | ||||
| ? | ED0362 | • • PLATE, NAME - 74D | 1 | ||||
| ? | TZ7519 | • • PLATE, NAME - MFDR | 1 | ||||
| ? | TZ7546 | • • PLATE, NAME - S6 | 1 | ||||
| ? | WA3108 | • • PLATE, HIGH VOLTAGE | 3 | ||||
| ? | TZ7518 | • • PLATE, NAME - GFDR | 1 | ||||
| ? | ED0364 | • • PLATE, NAME - 74 | 1 | ||||
| ? | ED0375 | • • PLATE, NAME - 74B | 1 | ||||
| ? | EC7463 | • • PLATE, NAME - FDT | 1 | ||||
| ? | PB3167 | • • TRANSFORMER, RIPPLE | 1 | ||||
| ? | MM0460 | • • FLAT WASHER - M8 | 2 | ||||
| ? | MM0470 | • • LOCKWASHER - M8 | 2 | ||||
| ? | MM0177 | • • NUT - M8 X 1.25 | 2 | ||||
| ? | TZ7517 | • • PLATE, NAME - FDP | 1 | ||||
| ? | PB5430 | • • INSULATOR | 6 | ||||
| ? | VC1390 | • • LOCKWASHER - 5/8" | 12 | ||||
| ? | TR9082 | • • FLAT WASHER - 5/8" | 24 | ||||
| ? | VC5162 | • • CAPSCREW - 5/8" - 11NC X 1 1/4" | 6 | ||||
| ? | ED5374 | • • BAR, BUS | 1 | ||||
| ? | EC9114 | • • SPACER, COPPER | 1 | ||||
| ? | ED2910 | • • BAR, BUS | 1 | ||||
| ? | TR4434 | • • CAPSCREW - 3/8" - 16NC X 2" | 2 | ||||
| ? | TC1231 | • • LOCKWASHER - 3/8" | 2 | ||||
| ? | TC1233 | • • NUT - 3/8" - 16NC | 2 | ||||
| ? | ED0372 | • • PLATE, NAME - 74E | 1 | ||||
| ? | ED0369 | • • PLATE, NAME - 71K | 1 | ||||
| ? | PB3348 | • • INSULATOR | 4 | ||||
| ? | TR5445 | • • LOCKWASHER - #6 | 4 | ||||
| ? | TR6008 | • • FLAT WASHER - 1/2" | 4 | ||||
| ? | PB3347 | • • SHUNT | 2 | ||||
| ? | VC1387 | • • CAPSCREW - 1/2" - 13NC X 1" | 4 | ||||
| ? | TZ7547 | • • PLATE, NAME - S7 | 1 | ||||
| ? | ED0361 | • • PLATE, NAME - 71G | 1 |
