| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | EC0466 | • COVER | 1 | ||||
| ? | MM0016 | • • CAPSCREW - M8 X 1.25 X 16 | 6 | ||||
| ? | MM0470 | • • LOCKWASHER - M8 | 6 | ||||
| ? | MM0460 | • • FLAT WASHER - M8 | 6 | ||||
| ? | EC0467 | • • COVER | 1 | ||||
| ? | MM0047 | • • CAPSCREW - M10 X 1.50 X 30 | 18 | ||||
| ? | MM0471 | • • LOCKWASHER - M10 | 18 | ||||
| ? | MM0461 | • • FLAT WASHER - M10 | 18 | ||||
| ? | PB8567 | • • INSULATOR, CENTER POST | 4 | ||||
| ? | VC1390 | • • LOCKWASHER - 5/8" | 8 | ||||
| ? | TR9082 | • • FLAT WASHER - 5/8" | 8 | ||||
| ? | TV1748 | • • CAPSCREW - 5/8" - 11NC X 1 1/2" | 2 | ||||
| ? | VC5162 | • • CAPSCREW - 5/8" - 11NC X 1 1/4" | 2 | ||||
| ? | CH2155 | • • CABLE - 7J1RS | 1 | ||||
| ? | ED0377 | • • PLATE, NAME - 75D | 1 | ||||
| ? | EC7469 | • • PLATE, NAME - 7J1RS | 1 | ||||
| ? | EC7455 | • • PLATE, NAME - S2 | 1 | ||||
| ? | ED0379 | • • PLATE, NAME - 75A | 1 | ||||
| ? | CH2156 | • • CABLE - 7J1LS | 1 | ||||
| ? | VZ2692 | • • LOCKNUT, CONDULET | 3 | ||||
| ? | CH2157 | • • CABLE - 7J1 | 1 | ||||
| ? | EC7468 | • • PLATE, NAME - 7J1LS | 1 | ||||
| ? | EC7454 | • • PLATE, NAME - S1 | 1 | ||||
| ? | ED0352 | • • PLATE, NAME - J71 | 1 | ||||
| ? | EC7269 | • • CABLE | 1 | ||||
| ? | ED0378 | • • PLATE, NAME - 75B | 1 | ||||
| ? | ED0376 | • • PLATE, NAME - 75C | 1 | ||||
| ? | WA3367 | • • NUT ASSM | 4 |
