Номер на схеме |
Каталожный номер |
Название |
Количество |
Детали |
|
|
|
? |
EC6159 |
• DUCT, INLET |
1 |
|
|
|
|
? |
TR1376 |
• • CAPSCREW - 1/2" - 13NC X 1 1/4" |
4 |
|
|
|
|
? |
TR6643 |
• • NUT - 1/2" |
4 |
|
|
|
|
? |
ED2338 |
• • CABINET CONTROL (SEE FIG 40564) |
1 |
|
|
|
|
? |
WA4729 |
• • FLAT WASHER - 5/8" (HARDENED) |
8 |
|
|
|
|
? |
VC1390 |
• • LOCKWASHER - 5/8" |
4 |
|
|
|
|
? |
VG2260 |
• • CAPSCREW - 5/8" - 11NC X 6" |
4 |
|
|
|
|
? |
TV1749 |
• • NUT - 5/8" |
4 |
|
|
|
|
? |
WA4730 |
• • FLAT WASHER - 3/4" (HARDENED) |
4 |
|
|
|
|
? |
TR4735 |
• • LOCKWASHER - 3/4" |
2 |
|
|
|
|
? |
VG2651 |
• • CAPSCREW - 3/4" - 10NC X 2 1/2" |
2 |
|
|
|
|
? |
TR8960 |
• • NUT - 3/4" |
2 |
|
|
|
|
? |
WA1060 |
• • CLAMP - T-BOLT |
2 |
|
|
|
|
? |
TY8672 |
• • HOSE |
1 |
|
|
|
|
? |
TZ1189 |
• • CLAMP |
1 |
|
|
|
|
? |
C1601 |
• • CAPSCREW - 3/8" - 16NC X 3/4" |
2 |
|
|
|
|
? |
TC1231 |
• • LOCKWASHER - 3/8" |
28 |
|
|
|
|
? |
TC1233 |
• • NUT - 3/8" - 16NC |
20 |
|
|
|
|
? |
TR5445 |
• • LOCKWASHER - #6 |
1 |
|
|
|
|
? |
EC9207 |
• • CLAMP |
1 |
|
|
|
|
? |
TK1427 |
• • GASKET |
1 |
|
|
|
|
? |
TD0791 |
• • CAPSCREW - 3/8" - 16NC X 1 1/4" |
10 |
|
|
|
|
? |
TY3653 |
• • TRANSITION |
1 |
|
|
|
|
? |
TY3656 |
• • BAR |
4 |
|
|
|
|
? |
TY3655 |
• • BOOT |
1 |
|
|
|
|
? |
JG9620 |
• • BAR |
4 |
|
|
|
|
? |
WA4497 |
• • CAPSCREW, SELF - TAPPING |
32 |
|
|
|
|
? |
TZ2254 |
• • HANDRAIL, LOWER |
1 |
|
|
|
|
? |
ED6383 |
• • DECK - REAR CENTER |
1 |
|
|
|
|
? |
WA0362 |
• • FLAT WASHER - 3/4" |
4 |
|
|
|
|
? |
C1542 |
• • LOCKWASHER - 3/4" |
4 |
|
|
|
|
? |
C1651 |
• • CAPSCREW - 3/4" - 10NC X 3 3/4" |
4 |
|
|
|
|
? |
C1527 |
• • NUT - 3/4" - 10NC |
4 |
|
|
|
|
? |
WA0720 |
• • FLAT WASHER - 3/8" (HARDENED) |
8 |
|
|
|
|
? |
TG5720 |
• • CAPSCREW - 3/8" - 16NC X 1" |
8 |
|
|
|
|
? |
TY0553 |
• • STRIP, SEAL - TOP & BOTTOM |
2 |
|
|
|
|
? |
TY0554 |
• • STRIP, SEAL - SIDES |
2 |
|
|
|
|
? |
PB6489 |
• • PANEL, RECTIFIFER |
1 |
|
|
|
|
? |
VS7026 |
• • COVER, LATCH |
1 |
|
|
|
|
? |
VF2231 |
• • MACHINE SCREW - #10 - 24NC X 3/8" |
2 |
|
|
|
|
? |
DC3101 |
• • LOCKWASHER - #10 |
2 |
|
|
|
|
? |
PB5508 |
• • PANEL, RESISTOR |
1 |
|
|
|
|
? |
TY3398 |
• • COVER |
1 |
|
|
|
|
? |
WA1738 |
• • SCREW, SELF LOCKING |
6 |
|
|
|
