| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | VE6968 | • TUBE, OVERFLOW | 1 | ||||
| ? | VE6969 | • • CLIP, HOSE | 4 | ||||
| ? | VE6830 | • • BAFFLE, AIR - BOTTOM FELT | 4 | ||||
| ? | VE4000 | • • GROMMET, RUBBER | 1420 | ||||
| ? | VE6967 | • • SUPPORT, CENTER | 2 | ||||
| ? | C0312 | • • LOCKWASHER - 3/8" | 26 | ||||
| ? | C1512 | • • NUT - 3/8" - 16NC | 52 | ||||
| ? | C1528 | • • NUT - 3/4" - 10NC | 12 | ||||
| ? | C1602 | • • CAPSCREW - 3/8" - 16NC X 1" | 38 | ||||
| ? | VE1285 | • • BRACKET, X-BRACE | 2 | ||||
| ? | C5747 | • • CAPSCREW - 5/16" - 18NC X 3/4" | 4 | ||||
| ? | VE5442 | • • FLAT WASHER - 5/16" | 6 | ||||
| ? | C1520 | • • NUT - 5/16" - 18NC | 2 | ||||
| ? | VE3458 | • • ROD, X-BRACE | 2 | ||||
| ? | VE6834 | • • BAFFLE | 2 | ||||
| ? | VE3999 | • • GROMMET, RUBBER | 1420 | ||||
| ? | VE4223 | • • TANK - TOP REAR | 1 | ||||
| ? | VE3441 | • • TANK - TOP FRONT | 1 | ||||
| ? | VE5320 | • • SUPPORT, CENTER | 2 | ||||
| ? | VE4005 | • • CAPSCREW - 3/8" - 16NC X 3/4" | 16 | ||||
| ? | C1614 | • • CAPSCREW - 1/2" - 13NC X 1 1/4" | 16 | ||||
| ? | C1540 | • • LOCKWASHER - 1/2" | 58 | ||||
| ? | VE3461 | • • NUT - 1/2" - 13NC | 16 | ||||
| ? | VE1219 | • • TUBE, STAY END | 64 | ||||
| ? | VE6827 | • • TANK - CENTER | 1 | ||||
| ? | VE6831 | • • SIDE MEMBER - RIGHT | 1 | ||||
| ? | VE6832 | • • SIDE MEMBER - LEFT | 1 | ||||
| ? | VE3460 | • • CAPSCREW - 1/2" - 13NC X 1" | 42 | ||||
| ? | VE6826 | • • TANK - BOTTOM FRONT | 1 | ||||
| ? | VE5317 | • • TANK - BOTTOM REAR | 1 | ||||
| ? | VE3449 | • • SIDE MEMBER - RIGHT | 1 | ||||
| ? | VE3450 | • • SIDE MEMBER - LEFT | 1 | ||||
| ? | VE3456 | • • RING, FAN | 1 | ||||
| ? | VE3457 | • • SHROUD | 1 | ||||
| ? | VE5319 | • • TANK - CENTER | 1 | ||||
| ? | VE3475 | • • TUBE | 564 | ||||
| ? | VE6829 | • • TUBE ASSM | 856 | ||||
| ? | VE5321 | • • BAFFLES, AIR - TOP FELT | 4 | ||||
| ? | C1603 | • • CAPSCREW - 3/8" - 16NC X 1 1/4" | 22 | ||||
| ? | E3735 | • • FLAT WASHER - 3/8" | 30 |
