| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | SEAL, DUST (1) | 1 | |||||
| ? | VE3080 | HOUSING/SPOOL/SLEEVE | 1 | ||||
| ? | VE3081 | BALL - 8.5 MM/0.33" | 1 | ||||
| ? | VE3082 | BUSHING, THREADED | 1 | ||||
| ? | O-RING (1) | 1 | |||||
| ? | KIN-RING (1) | 1 | |||||
| ? | VE3083 | BEARING ASSM | 1 | ||||
| ? | VE3084 | RING | 1 | ||||
| ? | VE3085 | PIN, CROSS | 1 | ||||
| ? | VE3086 | SPRING SET | 1 | ||||
| ? | VE3087 | SHAFT, CARDAN | 1 | ||||
| ? | VE3094 | SPACER | 1 | ||||
| ? | VE3088 | SPACER - 33.5 MM/1.32" | 1 | ||||
| ? | O-RING (1) | 1 | |||||
| ? | VE3089 | PLATE, DISTRIBUTOR | 1 | ||||
| ? | VE3090 | GEAR WHEEL SET | 1 | ||||
| ? | O-RING (1) | 2 | |||||
| ? | VE3091 | COVER, END | 1 | ||||
| ? | WASHER (1) | 7 | |||||
| ? | VE3092 | PIN, ROLL | 1 | ||||
| ? | VE3093 | CAPSCREW - M8 X 90 MM | 1 | ||||
| ? | MM0401 | CAPSCREW - M8 X 90 MM | 6 | ||||
| ? | NAME PLATE (2) | 1 | |||||
| ? | DRIVE SCREW (2) | 2 | |||||
| ? | VE3095 | NOTE: (1) INCLUDED IN VE3095 SEAL KIT. | |||||
| ? | (2) NOT SVCD SEPARATELY. |
