| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | PB9813 | TRANSFORMER, ISOLATION | 1 | ||||
| ? | DL4172 | SLEEVE, INSULATING | 4 | ||||
| ? | SF9896 | DISCONNECT, KNIFE | 4 | ||||
| ? | VZ2691 | LOCKNUT | 1 | ||||
| ? | EF9757 | HARNESS - PAYLOAD METER | 1 | ||||
| ? | ED5818 | HARNESS - PLM CONTROL | 1 | ||||
| ? | SM1947 | RELAY BOARD ASSM - RB2 | 1 | ||||
| ? | MM0469 | LOCKWASHER - M6 | 4 | ||||
| ? | MM0459 | FLAT WASHER - M6 | 4 | ||||
| ? | MM0176 | NUT - M6 X 1.00 | 4 | ||||
| ? | VZ0598 | TYRAP | 16 | ||||
| ? | WA2550 | SCREW, #10 - 24NC X 3/4" | 2 | ||||
| ? | EG2577 | HOUSING | 1 | ||||
| ? | EG2576 | HOUSING | 1 | ||||
| ? | EG2050 | HOUSING | 1 | ||||
| ? | EG2049 | HOUSING | 1 | ||||
| ? | EG2048 | RESISTOR, 250 OHM; 3 WATT | 4 |
