| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | VE3828 | SPOOLING SECTION ASSM | 1 | ||||
| ? | VJ1967 | • CAP | 1 | ||||
| ? | VJ1962 | • SPACER | 1 | ||||
| ? | VJ1975 | • SNAP RING | 1 | ||||
| ? | VJ1972 | • BALL | 4 | ||||
| ? | VJ1964 | • PIN, DETENT | 1 | ||||
| ? | VJ1960 | • SPRING | 1 | ||||
| ? | VE3823 | • SPACER | 1 | ||||
| ? | VJ1957 | • CAPSCREW | 2 | ||||
| ? | VE3820 | • POPPET, CHECK VALVE | 1 | ||||
| ? | VE3826 | • SPRING | 1 | ||||
| ? | VE3819 | • O-RING | 2 | ||||
| ? | VE3818 | • O-RING | 2 | ||||
| ? | VJ1947 | • WIPER | 2 | ||||
| ? | • SPOOL (1) | 1 | |||||
| ? | VJ0012 | • MACHINE SCREW | 2 | ||||
| ? | VJ1943 | • PLATE, SEAL | 2 | ||||
| ? | • HOUSING, SPOOL | 1 | |||||
| ? | VJ1944 | • SEAT, SPRING | 2 | ||||
| ? | VJ1961 | • SPRING | 1 | ||||
| ? | VJ1974 | • BALL | 1 | ||||
| ? | VE3825 | • SLEEVE, DETENT | 1 | ||||
| ? | VE3827 | HOUSING, INLET | 1 | ||||
| ? | VE3829 | HOUSING, OUTLET | 1 | ||||
| ? | VE3821 | ROD, TIE | 2 | ||||
| ? | VJ1934 | NUT | 2 | ||||
| ? | VE3822 | ROD, TIE | 1 | ||||
| ? | VJ1933 | NUT | 1 | ||||
| ? | VE3830 | PLUG, SHUT-OFF ASSM | 1 | ||||
| ? | VE3979 | VALVE, RELIEF | 1 | ||||
| ? | NOTE: (1) NOT SVCD SEPARATELY. |
