Каталог Komatsu

k-part

Номер на схеме	Каталожный номер	Название	Количество
?	VE3758	PLUG	16
?		O-RING (1)	16
?		SHIELD (1)	2
?	VE3759	PIN	16
?	VE3760	SPRING	2
?	VE3761	PISTON	16
?	VE2129	SNAP RING	1
?		SEAL (1)	1
?	VE3762	FITTING	16
?		O-RING (1)	16
?	VE3763	SPRING	16
?	VE3141	DISK	16
?	VE2140	GUIDE	16
?	VE3764	VALVE SEAT	8
?	VE3765	VALVE, INLET (2)	8
?		O-RING (1)/(2)	1
?	VE3766	DRAIN PLUG (2)	1
?	VE3767	HOUSING	1
?		HOUSING/CONTROL VALVE (SEE FOLLOWING PG)	1
?		O-RING (1)	1
?	VE2143	CUP, BEARING	2
?	VE2144	CONE, BEARING	2
?	VE2145	SPACER	2
?	VE2146	THRUST WASHER	4
?	VE3147	BEARING RACE	2
?		RING, SEALING (1)	1
?	VE3754	SHAFT	1
?	VE3755	WASHER	6
?	VE3756	PIN	100
?	VE2151	SHIM
?	VE2152	SHIM
?		O-RING (1)	1
?	VE3765	VALVE	8
?	VE3764	VALVE SEAT	8
?	VE3768	HOUSING	1
?	VE2140	GUIDE	8
?	VE3141	DISK	8
?	VE3763	SPRING	8
?		O-RING (1)	1
?	VE3762	FITTING	8
?		O-RING (1)	1
?	VE3769	PLUG	1
?		O-RING (1)	4
?	VE3770	CAPSCREW	4
?	VE7124	SUPPORT	1
?	VE7125	SPACER	1
?	VE7126	O-RING	1
?	VE3789	NOTE: (1) INCLUDED IN VE3789 SEAL KIT.
?		(2) INCLUDED IN VE3767 HOUSING.
