| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | EB0867 | • HARNESS, INCLINOMETER | 1 | ||||
| ? | EB0851 | • • HARNESS, REAR & R.H. SENSOR | 1 | ||||
| ? | EB0862 | • • HARNESS, L.H. SENSOR | 1 | ||||
| ? | YA2171 | • • HARNESS, PAYLOAD METER | 1 | ||||
| ? | TC6058 | • • CLAMP, VINYL | 1 | ||||
| ? | TC1233 | • • NUT - 3/8" - 16NC | 2 | ||||
| ? | TC1231 | • • LOCKWASHER - 3/8" | 2 | ||||
| ? | TR4436 | • • FLAT WASHER - 3/8" | 2 | ||||
| ? | SF9896 | • • DISCONNECT, KNIFE | 1 | ||||
| ? | WA3367 | • • NUT ASSM | 11 | ||||
| ? | PB4767 | • • RELAY | 4 | ||||
| ? | VC5344 | • • FLAT WASHER - #10 | 4 | ||||
| ? | DF0017 | • • NUT - #10 - 24NC | 4 | ||||
| ? | DC3101 | • • LOCKWASHER - #10 | 4 | ||||
| ? | TG1929 | • • MACHINE SCREW - #10 - 24NC X 1/2" | 4 | ||||
| ? | EB4078 | • • COVER | 1 | ||||
| ? | KD0251 | • • MACHINE SCREW - 1/4" - 20NC X 1/2" | 2 | ||||
| ? | TA7409 | • • INSULATOR, STAND-OFF | 1 | ||||
| ? | DC3584 | • • LOCKWASHER - 1/4" | 3 | ||||
| ? | SP8417 | • • FLAT WASHER - 1/4" | 3 | ||||
| ? | EB0865 | • • JUMPER, METRIC TON DISPLAY | 1 | ||||
| ? | PB6073 | • • BREAKER, CIRCUIT - 15 AMP | 1 | ||||
| ? | PB6072 | • • BREAKER, CIRCUIT - 5 AMP | 1 | ||||
| ? | TD0794 | • • CAPSCREW - 5/16" - 18NC X 3/4" | 2 | ||||
| ? | TD1684 | • • NUT - 5/16" - 18NC | 2 | ||||
| ? | TV0177 | • • FLAT WASHER - 5/16" | 2 | ||||
| ? | SC4174 | • • LOCKWASHER - 5/16" | 2 | ||||
| ? | EB3780 | • • MODULE, DATA STORAGE TRIGGER | 1 | ||||
| ? | WA2853 | • • SET SCREW - #12 - 24NC X 5/8" | 24 | ||||
| ? | TF6925 | • • CLAMP, VINYL | 1 | ||||
| ? | TC1234 | • • CAPSCREW - 3/8" - 16NC X 3/4" | 1 | ||||
| ? | MM0357 | • • MACHINE SCREW - M6 X 1" | 2 | ||||
| ? | EB4076 | • • HOUSING, PAYLOAD METER | 1 | ||||
| ? | EB3778 | • • HOUSING | 1 | ||||
| ? | H3043 | • • GROMMET, RUBBER | 1 | ||||
| ? | TD1549 | • • NUT - 1/4" - 20NC | 1 | ||||
| ? | VE5548 | • • ROLL PAPER, THERMAL | 10 |
