| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | EB3786 | • METER, PAYLOAD | 1 | ||||
| ? | EB3796 | • • PROM, PROGRAMMED | 1 | ||||
| ? | PB8001 | • • PROM | 1 | ||||
| ? | SM0396 | • • DECAL | 1 | ||||
| ? | 781-84-34000 | • • METER | 1 | ||||
| ? | 781-82-72860 | • • BATTERY | 1 | ||||
| ? | 781-82-72910 | • • ROLL, PAPER | 10 | ||||
| ? | YA2171 | • • HARNESS, PAYLOAD METER | 1 | ||||
| ? | EB0851 | • • HARNESS, REAR & R.H. SENSOR | 1 | ||||
| ? | EB0862 | • • HARNESS, L.H. SENSOR | 1 | ||||
| ? | EB0867 | • • HARNESS, INCLINOMETER | 1 | ||||
| ? | EB0861 | • • BRACKET, INCLINOMETER | 1 | ||||
| ? | TG5720 | • • CAPSCREW - 3/8" - 16NC X 1" | 5 | ||||
| ? | TC1231 | • • LOCKWASHER - 3/8" | 5 | ||||
| ? | EB0860 | • • PLATE, MOUNTING | 1 | ||||
| ? | TF6925 | • • CLAMP, VINYL | 3 | ||||
| ? | WA2853 | • • SET SCREW - #12 - 24NC X 5/8" | 3 | ||||
| ? | DF3445 | • • FLAT WASHER - #12 | 3 | ||||
| ? | VD2047 | • • LOCKWASHER | 3 | ||||
| ? | TC1233 | • • NUT - 3/8" - 16NC | 3 | ||||
| ? | TR4436 | • • FLAT WASHER - 3/8" | 3 | ||||
| ? | 786-19-25330 | • • ANGLE, SENSOR | 1 | ||||
| ? | VN6396 | • • GRIP, CORD | 2 | ||||
| ? | VM5588 | • • LOCKNUT | 2 | ||||
| ? | VG5704 | • • BUSHING | 2 | ||||
| ? | VY8331 | • • CLAMP, VINYL | 1 | ||||
| ? | PB0227 | • • RING, TERMINAL | 2 |
