| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | HC9043 | • DISCONNECT, KNIFE | 2 | ||||
| ? | HC9047 | • • SLEEVE, CONNECTOR | 2 | ||||
| ? | TG5720 | • • CAPSCREW - 3/8" - 16NC X 1" | 2 | ||||
| ? | TR4436 | • • FLAT WASHER - 3/8" | 6 | ||||
| ? | TC1231 | • • LOCKWASHER - 3/8" | 6 | ||||
| ? | TC1233 | • • NUT - 3/8" - 16NC | 6 | ||||
| ? | TY6299 | • • CABLE - 74A | 1 | ||||
| ? | TY6293 | • • CABLE - 7J3 | 1 | ||||
| ? | EB3459 | • • BAR, BUS - RP2-RP1 | 1 | ||||
| ? | VC6500 | • • CAPSCREW - 1/2" - 13NC X 2" | 3 | ||||
| ? | VC7836 | • • FLAT WASHER - 1/2" | 8 | ||||
| ? | TR5445 | • • LOCKWASHER - 1/2" | 4 | ||||
| ? | TR6643 | • • NUT - 1/2" - 13NC | 4 | ||||
| ? | EB7685 | • • BAR, BUS - RP1/RP2 - L.T. | 1 | ||||
| ? | TY2724 | • • BAR, BUS | 1 | ||||
| ? | VC8762 | • • CAPSCREW - 3/8" - 16NC X 1 1/2" | 1 | ||||
| ? | VS0035 | • • DOME LIGHT | 2 | ||||
| ? | SR6747 | • • LAMP, MINIATURE | 2 | ||||
| ? | TM9090 | • • INSULATOR | 2 | ||||
| ? | TZ7505 | • • NAME PLATE (RP4) | 1 | ||||
| ? | TZ7506 | • • NAME PLATE (RP5) | 1 | ||||
| ? | TZ7507 | • • NAME PLATE (MF) | 1 | ||||
| ? | TZ7508 | • • NAME PLATE (GF) | 1 | ||||
| ? | TZ7504 | • • NAME PLATE (RP3) | 1 | ||||
| ? | VM4237 | • • HOSE | 1 | ||||
| ? | TZ7509 | • • NAME PLATE (P2) | 1 | ||||
| ? | TZ7510 | • • NAME PLATE (RP2) | 1 | ||||
| ? | TZ7511 | • • NAME PLATE (RP1) | 1 | ||||
| ? | TZ7512 | • • NAME PLATE (P1) | 1 | ||||
| ? | PB5592 | • • CONTACTOR | 1 | ||||
| ? | PB2052 | • • INSULATION | 2 | ||||
| ? | VW6069 | • • BOLT, INSULATED | 3 | ||||
| ? | VW6070 | • • SHIELD | 2 | ||||
| ? | TA0603 | • • FITTING, NYLON | 1 | ||||
| ? | TN9637 | • • BAR, BUS | 1 | ||||
| ? | VC6561 | • • CAPSCREW - 1/2" - 13NC X 1 1/2" | 1 | ||||
| ? | TM4559 | • • TUBE, NYLON | 1 | ||||
| ? | TA0602 | • • FITTING, NYLON | 1 | ||||
| ? | TM4557 | • • ADAPTOR | 1 | ||||
| ? | TK1977 | • • GASKET | 1 | ||||
| ? | TH6086 | • • FITTING, TUBE | 1 |
