| Наименование | Страница | Код страницы |
|---|---|---|
| MIRROR INSTALLATION | 014 | 30087 |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | EB1101 | LADDER - L.H. | 1 | ||||
| ? | YA2341 | COVER - L.H. | 1 | ||||
| ? | TZ1187 | PAD | 2 | ||||
| ? | C1612 | CAPSCREW - 1/2" - 13NC X 1" | 25 | ||||
| ? | C1549 | FLAT WASHER - 1/2" | 3 | ||||
| ? | C1657 | CAPSCREW - 3/4" - 10NC X 5 1/2" | 4 | ||||
| ? | TF2449 | FLAT WASHER - 3/4" | 4 | ||||
| ? | AK1212 | MIRROR (SEE FIG 30087) | 1 | 30087 | |||
| ? | TY8384 | HANDRAIL - LEFT FRONT | 1 | ||||
| ? | YA1963 | HANDRAIL - LEFT REAR | 1 | ||||
| ? | C1540 | LOCKWASHER - 1/2" | 22 | ||||
| ? | TY8388 | BLOCK, TAPPED | 1 | ||||
| ? | C1603 | CAPSCREW - 3/8" - 16NC X 1 1/4" | 6 | ||||
| ? | EB2899 | WASHER - 3/8" | 2 | ||||
| ? | C0312 | LOCKWASHER - 3/8" | 14 | ||||
| ? | EB2104 | STRAP, MOUNTING - R.H. | 1 | ||||
| ? | EB2105 | STRAP, MOUNTING - L.H. | 1 | ||||
| ? | C1605 | WASHER - 3/8" | 10 | ||||
| ? | EB2102 | WASHER - 3/8" | 2 | ||||
| ? | C1521 | NUT - 3/8" - 16NC | 8 | ||||
| ? | EB2101 | STEP | 1 |
