| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 419-62-53670 | Hose | 1 | SN: H70051- KIT-FLAG: _- SCC: SERIALNO: H70051- |
|||
| ? | 419-62-51150 | Bracket | 1 | SN: H70051- KIT-FLAG: _- SCC: SERIALNO: H70051- |
|||
| ? | 01010-81025 | Bolt | 2 | SN: H70051- KIT-FLAG: _- SCC: SERIALNO: H70051- |
|||
| ? | 01643-31032 | Washer | 2 | SN: H70051- KIT-FLAG: _- SCC: SERIALNO: H70051- |
|||
| ? | 04434-53211 | Clip | 1 | SN: H70051- KIT-FLAG: _- SCC: SERIALNO: H70051- |
|||
| ? | 07095-20523 | Cushion | 1 | SN: H70051- KIT-FLAG: _- SCC: SERIALNO: H70051- |
|||
| ? | 01010-81025 | Bolt | 1 | SN: H70051- KIT-FLAG: _- SCC: SERIALNO: H70051- |
|||
| ? | 01643-31032 | Washer | 1 | SN: H70051- KIT-FLAG: _- SCC: SERIALNO: H70051- |
|||
| ? | 7861-93-1870 | Sensor, Pressure, Hydraulic Pump | 1 | SN: H70051- KIT-FLAG: _- SCC: SERIALNO: H70051- |
|||
| ? | 07002-61823 | • O-Ring | 1 | SN: H70051- KIT-FLAG: _- SCC: SERIALNO: H70051- |
|||
| ? | 02781-0021D | Union | 1 | SN: H70051- KIT-FLAG: _- SCC: SERIALNO: H70051- |
|||
| ? | 07002-11423 | O-Ring | 1 | SN: H70051- KIT-FLAG: _- SCC: SERIALNO: H70051- |
|||
| ? | 02896-11008 | O-Ring | 1 | SN: H70051- KIT-FLAG: _- SCC: SERIALNO: H70051- |
|||
| ? | 02782-1021A | Elbow | 1 | SN: H70051- KIT-FLAG: _- SCC: SERIALNO: H70051- |
|||
| ? | 07002-11423 | O-Ring | 1 | SN: H70051- KIT-FLAG: _- SCC: SERIALNO: H70051- |
|||
| ? | 02896-11008 | O-Ring | 1 | SN: H70051- KIT-FLAG: _- SCC: SERIALNO: H70051- |
|||
| ? | 11Y-62-12390 | Union | 1 | SN: H70051- KIT-FLAG: _- SCC: SERIALNO: H70051- |
|||
| ? | 07002-11423 | O-Ring | 1 | SN: H70051- KIT-FLAG: _- SCC: SERIALNO: H70051- |
|||
| ? | 02896-11008 | O-Ring | 1 | SN: H70051- KIT-FLAG: _- SCC: SERIALNO: H70051- |
|||
| ? | 419-62-52260 | Tube | 1 | SN: H70051- KIT-FLAG: _- SCC: SERIALNO: H70051- |
|||
| ? | 07000-13035 | O-Ring | 1 | SN: H70051- KIT-FLAG: _- SCC: SERIALNO: H70051- |
|||
| ? | 01010-81060 | Bolt | 4 | SN: H70051- KIT-FLAG: _- SCC: SERIALNO: H70051- |
|||
| ? | 01643-31032 | Washer | 4 | SN: H70051- KIT-FLAG: _- SCC: SERIALNO: H70051- |
|||
| ? | 07283-33442 | Clip, Pipe | 1 | SN: H70051- KIT-FLAG: _- SCC: SERIALNO: H70051- |
|||
| ? | 07283-53444 | Seat | 1 | SN: H70051- KIT-FLAG: _- SCC: SERIALNO: H70051- |
|||
| ? | 01643-31032 | Washer | 2 | SN: H70051- KIT-FLAG: _- SCC: SERIALNO: H70051- |
|||
| ? | 01597-01009 | Nut | 2 | SN: H70051- KIT-FLAG: _- SCC: SERIALNO: H70051- |
|||
| ? | (419-62-52820) | Tee (Hydraulic Piping, with Quick Coupler, with Boom Piping) | KIT-FLAG: _- SCC: SERIALNO: - |
H4200-001006 | |||
| ? | (419-62-52820) | Tee (Hydraulic Piping, with Quick Coupler, without Boom Piping) | KIT-FLAG: _- SCC: SERIALNO: - |
H4200-002006 | |||
| ? | (419-62-52820) | Tee (Hydraulic Piping, without Quick Coupler, with Boom Piping) | KIT-FLAG: _- SCC: SERIALNO: - |
H4200-004006 | |||
| ? | (419-62-52820) | Tee (Hydraulic Piping, without Quick Coupler, without Boom Piping) | KIT-FLAG: _- SCC: SERIALNO: - |
H4200-005006 | |||
| ? | (419-62-52820) | Tee (Hydraulic Piping, with Loading Boom, with Quick Coupler, with Boom Piping) | KIT-FLAG: _- SCC: SERIALNO: - |
H4200-007006 | |||
| ? | (419-62-52820) | Tee (Hydraulic Piping, with Loading Boom, with Quick Coupler, without Boom Piping) | KIT-FLAG: _- SCC: SERIALNO: - |
H4200-008006 | |||
| ? | (419-62-52820) | Tee (Hydraulic Piping, with Loading Boom, without Quick Coupler) | KIT-FLAG: _- SCC: SERIALNO: - |
H4200-010006 | |||
| ? | (419-62-52820) | Tee (Hydraulic Piping, with High Lift Boom, with Quick Coupler, with Boom Piping) | KIT-FLAG: _- SCC: SERIALNO: - |
H4200-012006 | |||
| ? | (419-62-52820) | Tee (Hydraulic Piping, with High Lift Boom, with Quick Coupler, without Boom Piping) | KIT-FLAG: _- SCC: SERIALNO: - |
H4200-013006 | |||
| ? | (419-62-52820) | Tee (Hydraulic Piping, with High Lift Boom, without Quick Coupler) | KIT-FLAG: _- SCC: SERIALNO: - |
H4200-016006 |
