| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 707-00-0X180 | BOOM SWING CYLINDER, ASSEMBLY | 1 | SN: F80001- |
X | ||
| ? | 721-11-61910 | • CYLINDER | 1 | SN: F80001- |
|||
| ? | 707-76-30350 | • BUSHING | 1 | SN: F80001- |
|||
| ? | 707-29-60830 | • HEAD, CYLINDER | 1 | SN: F80001- |
|||
| ? | 07177-03025 | • BUSHING | 1 | SN: F80001- |
|||
| ? | 07179-12042 | • RING, SNAP | 1 | SN: F80001- |
|||
| ? | 721-58-30630 | • ROD, CYLINDER | 1 | SN: F80001- |
|||
| ? | 707-76-30380 | • BUSHING | 1 | SN: F80001- |
|||
| ? | 07020-00900 | • FITTING, GREASE | 1 | SN: F80001- |
|||
| ? | 707-36-60060 | • PISTON | 1 | SN: F80001- |
|||
| ? | 707-67-22010 | • NUT | 1 | SN: F80001- |
|||
| ? | 707-98-11220 | • KIT, GASKET | 1 | SN: F80001- |
|||
| ? | 07145-00030 | • • SEAL, DUST | 2 | SN: F80001- |
|||
| ? | 707-51-30210 | • • PACKING, ROD | 1 | SN: F80001- |
|||
| ? | 707-56-30510 | • • SEAL, DUST | 1 | SN: F80001- |
|||
| ? | 07000-12055 | • • O-RING | 1 | SN: F80001- |
|||
| ? | 07146-02056 | • • RING, BACK-UP | 1 | SN: F80001- |
|||
| ? | 07000-12060 | • • O-RING | 1 | SN: F80001- |
|||
| ? | 07145-00030 | • • SEAL, DUST | 2 | SN: F80001- |
|||
| ? | 707-44-60180 | • • SEAL, DUST | 1 | SN: F80001- |
|||
| ? | 707-39-60190 | • • RING | 1 | SN: F80001- |
