| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 702-16-05261 | Valve, Pilot | 1 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | • Body, Valve | 1 | SN: K75001- KIT-FLAG: _- SCC: C1 SERIALNO: K75001- |
||||
| ? | • Valve | 2 | SN: K75001- KIT-FLAG: _- SCC: C1 SERIALNO: K75001- |
||||
| ? | • Shim, T=0.30mm | 2 | SN: K75001- KIT-FLAG: _- SCC: C1 SERIALNO: K75001- |
||||
| ? | • Spring, L=22.73mm | 2 | SN: K75001- KIT-FLAG: _- SCC: C1 SERIALNO: K75001- |
||||
| ? | • Spring, L=22.75mm | 2 | SN: K75001- KIT-FLAG: _- SCC: C1 SERIALNO: K75001- |
||||
| ? | • Retainer, T=5.9mm | 2 | SN: K75001- KIT-FLAG: _- SCC: C1 SERIALNO: K75001- |
||||
| ? | • Retainer, T=5.7mm | 2 | SN: K75001- KIT-FLAG: _- SCC: C1 SERIALNO: K75001- |
||||
| ? | • Retainer, T=5.7mm | 2 | SN: K75001- KIT-FLAG: _- SCC: C1 SERIALNO: K75001- |
||||
| ? | • Retainer, T=5.5mm | 2 | SN: K75001- KIT-FLAG: _- SCC: C1 SERIALNO: K75001- |
||||
| ? | • Spring, L=33.88mm | 2 | SN: K75001- KIT-FLAG: _- SCC: C1 SERIALNO: K75001- |
||||
| ? | • Piston | 2 | SN: K75001- KIT-FLAG: _- SCC: C1 SERIALNO: K75001- |
||||
| ? | 702-16-51270 | • Seal | 2 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 702-16-54580 | • Collar | 2 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 702-16-54590 | • O-Ring | 2 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | • Lever | 1 | SN: K75001- KIT-FLAG: _- SCC: C1 SERIALNO: K75001- |
||||
| ? | • Plate | 1 | SN: K75001- KIT-FLAG: _- SCC: C1 SERIALNO: K75001- |
||||
| ? | • Shaft | 1 | SN: K75001- KIT-FLAG: _- SCC: C1 SERIALNO: K75001- |
||||
| ? | 702-16-54641 | • Boot | 1 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 01252-60625 | • Bolt | 2 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 702-16-54660 | • Plate | 1 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 702-16-54650 | • Plate | 2 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 702-16-54670 | • Shim, T=0.20mm | 4 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | • Solenoid Assembly | 1 | SN: K75001- KIT-FLAG: _- SCC: C1 SERIALNO: K75001- |
||||
| ? | 702-21-53680 | • • O-Ring | 1 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | • Spool | 1 | SN: K75001- KIT-FLAG: _- SCC: C1 SERIALNO: K75001- |
||||
| ? | • Plug | 1 | SN: K75001- KIT-FLAG: _- SCC: C1 SERIALNO: K75001- |
||||
| ? | 702-21-53311 | • Spring, L=9.5mm | 1 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 702-21-53340 | • Spring, L=9.1mm | 1 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 702-21-53350 | • Spring, L=9.9mm | 1 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 702-22-13250 | • Spring, L=8.7mm | 1 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 702-16-56490 | • Filter | 1 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | • Plug | 2 | SN: K75001- KIT-FLAG: _- SCC: C1 SERIALNO: K75001- |
||||
| ? | 01252-60620 | • Bolt | 2 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
