| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 2A5-03-11791 | Cover | 1 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | • Cover | 1 | SN: K75001- KIT-FLAG: _- SCC: C1 SERIALNO: K75001- |
||||
| ? | 2A5-03-11780 | • Sheet | 1 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 01010-81020 | Bolt | 2 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 01643-31032 | Washer | 2 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 2A6-03-11542 | Sheet | 1 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 2A6-03-11550 | Sheet | 1 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 2A5-03-11881 | Sheet | 1 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 2A6-03-11532 | Sheet | 1 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 2A6-03-11770 | Sheet | 1 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 2A5-03-11930 | Sheet | 1 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 20Y-979-6191 | Sensor | 1 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 20Y-979-6271 | Bracket | 1 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 01010-80616 | Bolt | 1 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 01643-30623 | Washer | 1 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 6560-61-7300 | Sensor, Temperature | 1 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 6735-21-1930 | • O-Ring | 1 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 22U-03-31170 | Shroud | 1 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 01010-81030 | Bolt | 6 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 203-54-56970 | Washer | 6 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 20Y-00-42170 | Plate | 1 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 2A5-03-25270 | Joint | 1 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 01010-81230 | Bolt | 2 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 01643-31232 | Washer | 2 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 2A6-01-12741 | Hose Assembly | 1 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 11Y-09-11140 | Clip | 1 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 11Y-09-11140 | Clip | 1 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 2A6-01-12891 | Hose | 1 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 09479-12400 | Clip | 1 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 09479-12400 | Clip | 1 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | (2A6-01-12751) | Hose Assembly | KIT-FLAG: _- SCC: SERIALNO: - |
D0510-001002 |
