| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 56B-13-20004 | Transmission Assembly | 1 | SN: 7030- KIT-FLAG: _- SCC: SERIALNO: 7030- |
|||
| ? | 56B-15-22032 | • Clutch Assembly, 2nd and 3rd | 1 | SN: 7030- KIT-FLAG: _- SCC: SERIALNO: 7030- |
|||
| ? | 56B-15-22131 | • • Shaft and Cylinder Assembly, 2nd and 3rd | 1 | SN: 7030- KIT-FLAG: _- SCC: SERIALNO: 7030- |
|||
| ? | • • • Shaft, Lower | 1 | SN: 7030- KIT-FLAG: _- SCC: C1 SERIALNO: 7030- |
||||
| ? | 56D-15-29790 | • • • Plug | 2 | SN: 7030- KIT-FLAG: _- SCC: SERIALNO: 7030- |
|||
| ? | • • • Housing, 2nd and 3rd | 1 | SN: 7030- KIT-FLAG: _- SCC: C1 SERIALNO: 7030- |
||||
| ? | 56B-15-12650 | • • Piston | 1 | SN: 7030- KIT-FLAG: _- SCC: SERIALNO: 7030- |
|||
| ? | 56B-15-12660 | • • Piston | 1 | SN: 7030- KIT-FLAG: _- SCC: SERIALNO: 7030- |
|||
| ? | 714-07-12670 | • • Disc | 20 | SN: 7030- KIT-FLAG: _- SCC: SERIALNO: 7030- |
|||
| ? | 714-07-12680 | • • Plate, Separate | 22 | SN: 7030- KIT-FLAG: _- SCC: SERIALNO: 7030- |
|||
| ? | 714-07-12781 | • • Spring | 20 | SN: 7030- KIT-FLAG: _- SCC: SERIALNO: 7030- |
|||
| ? | 714-07-12711 | • • Plate, End | 2 | SN: 7030- KIT-FLAG: _- SCC: SERIALNO: 7030- |
|||
| ? | 714-07-12720 | • • Ring, Snap | 2 | SN: 7030- KIT-FLAG: _- SCC: SERIALNO: 7030- |
|||
| ? | 714-16-19210 | • • Seal Ring, (Kit : K01) | 2 | SN: 7030- KIT-FLAG: _- SCC: SERIALNO: 7030- |
|||
| ? | 714-07-12740 | • • Seal Ring, (Kit : K01) | 1 | SN: 7030- KIT-FLAG: _- SCC: SERIALNO: 7030- |
|||
| ? | 56B-15-19210 | • • Seal Ring, (Kit : K01) | 1 | SN: 7030- KIT-FLAG: _- SCC: SERIALNO: 7030- |
|||
| ? | 56B-15-19530 | • • Washer, Thrust | 1 | SN: 7030- KIT-FLAG: _- SCC: SERIALNO: 7030- |
|||
| ? | 56B-15-19520 | • • Washer, Thrust | 3 | SN: 7030- KIT-FLAG: _- SCC: SERIALNO: 7030- |
|||
| ? | 56B-15-19411 | • • Bearing, Needle | 1 | SN: 7030- KIT-FLAG: _- SCC: SERIALNO: 7030- |
|||
| ? | 56B-15-19422 | • • Bearing, Needle | 1 | SN: 7030- KIT-FLAG: _- SCC: SERIALNO: 7030- |
|||
| ? | 56B-15-32940 | • • Spacer | 1 | SN: (102285- KIT-FLAG: _- SCC: SERIALNO: (102285)- |
|||
| ? | 56B-15-12942 | • • Spacer | 1 | SN: 7030-(102284 KIT-FLAG: _- SCC: SERIALNO: 7030-(102284) |
|||
| ? | 56B-15-32460 | • • Gear | 1 | SN: (102285- KIT-FLAG: _- SCC: SERIALNO: (102285)- |
|||
| ? | 56B-15-22460 | • • Gear | 1 | SN: 7030-(102284 KIT-FLAG: _- SCC: SERIALNO: 7030-(102284) |
|||
| ? | 56B-15-32450 | • • Gear | 1 | SN: (102285- KIT-FLAG: _- SCC: SERIALNO: (102285)- |
|||
| ? | 56B-15-12451 | • • Gear | 1 | SN: 7030-(102284 KIT-FLAG: _- SCC: A2 SERIALNO: 7030-(102284) |
|||
| ? | 56B-15-12552 | • • Gear | 1 | SN: 7030- KIT-FLAG: _- SCC: SERIALNO: 7030- |
|||
| ? | 56B-15-12960 | • • Spacer | 1 | SN: 7030- KIT-FLAG: _- SCC: SERIALNO: 7030- |
|||
| ? | 04066-00075 | • • Ring, Snap | 1 | SN: 7030- KIT-FLAG: _- SCC: SERIALNO: 7030- |
|||
| ? | 56B-15-19311 | • • Bearing, Taper Roller | 2 | SN: 7030- KIT-FLAG: _- SCC: SERIALNO: 7030- |
|||
| ? | 56B-15-12971 | • • Spacer | 1 | SN: 7030- KIT-FLAG: _- SCC: SERIALNO: 7030- |
|||
| ? | 56B-15-12980 | • • Spacer | 1 | SN: 7030- KIT-FLAG: _- SCC: SERIALNO: 7030- |
|||
| ? | 56D-15-19250 | • Seal Ring, (Kit : K01) | 3 | SN: 7030- KIT-FLAG: _- SCC: SERIALNO: 7030- |
