| Наименование | Страница | Код страницы |
|---|---|---|
| TRANSMISSION (1/9) | C-3220 | 3220 |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (42N-15-11502) | TRANSMISSION , ASSEMBLY | 1 | SN: F30541- |
3220 | ||
| ? | CA0123918 | • BOLT | 1 | SN: F30541- |
|||
| ? | CA0129924 | • WASHER | 1 | SN: F30541- |
|||
| ? | CA0028131 | • O-RING | 1 | SN: F30541- |
|||
| ? | CA0025809 | • BEARING | 1 | SN: F30541- |
|||
| ? | CA0024799 | • SEEGER | 1 | SN: F30541- |
|||
| ? | CA0106866 | • SHIM, 0.100 MM | 1 | SN: F30541- |
A | ||
| ? | CA0106867 | • SHIM, 0.300 mm | 1 | SN: F30541- |
B | ||
| ? | CA0106868 | • SHIM, 0.500 mm | 1 | SN: F30541- |
C | ||
| ? | CA0138391 | • THRUST WASHER | 1 | SN: F30541- |
|||
| ? | CA0138399 | • WASHER | 6 | SN: F30541- |
|||
| ? | CA0138394 | • SPACER | 1 | SN: F30541- |
|||
| ? | CA0028548 | • O-RING | 1 | SN: F30541- |
|||
| ? | CA0139341 | • CLUTCH, PISTON | 1 | SN: F30541- |
|||
| ? | CA0028624 | • O-RING | 1 | SN: F30541- |
|||
| ? | CA0138384 | • BRAKE PLATE | 1 | SN: F30541- |
|||
| ? | CA0068703 | • KIT, 4WD OUTPUT SHAFT | 1 | SN: F30541- |
|||
| ? | CA0023834 | • • RIVET | 1 | SN: F30541- |
|||
| ? | CA0139197 | • • SEAL | 2 | SN: F30541- |
|||
| ? | CA0028523 | • • O-RING | 1 | SN: F30541- |
|||
| ? | CA0138986 | • • SWING CIRCLE | 1 | SN: F30541- |
|||
| ? | CA0139342 | • PIN, BRAKE | 3 | SN: F30541- |
|||
| ? | CA0028534 | • O-RING | 3 | SN: F30541- |
|||
| ? | CA0149305 | • KIT, CLUTCH | 1 | SN: F30541- |
|||
| ? | CA0141114 | • LOCK, RING | 1 | SN: F30541- |
|||
| ? | CA0025009 | • LOCK, RING | 1 | SN: F30541- |
|||
| ? | CA0642122 | • GEAR | 1 | SN: F30541- |
|||
| ? | CA0027956 | • ROLLER BEARING | 1 | SN: F30541- |
|||
| ? | CA0139011 | • SWING CIRCLE | 1 | SN: F30541- |
|||
| ? | CA0025829 | • BEARING | 1 | SN: F30541- |
|||
| ? | CA0144452 | • FLANGE | 1 | SN: F30541- |
|||
| ? | CA0025485 | • SEAL | 1 | SN: F30541- |
|||
| ? | CA0368059 | • HOUSING | 1 | SN: F30541- |
