| Наименование | Страница | Код страницы |
|---|---|---|
| TRANSMISSION (1/9) | C-3220 | 3220 |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (42N-15-11502) | TRANSMISSION , ASSEMBLY | 1 | SN: F30541- |
3220 | ||
| ? | CA0025808 | • BEARING | 2 | SN: F30541- |
|||
| ? | CA0137647 | • SHAFT | 1 | SN: F30541- |
|||
| ? | CA0025859 | • BEARING | 1 | SN: F30541- |
|||
| ? | CA0133174 | • GEAR | 1 | SN: F30541- |
|||
| ? | CA0024805 | • SEEGER | 1 | SN: F30541- |
|||
| ? | CA0138986 | • SWING CIRCLE | 2 | SN: F30541- |
|||
| ? | CA0027956 | • ROLLER BEARING | 1 | SN: F30541- |
|||
| ? | CA0148635 | • GEAR | 1 | SN: F30541- |
|||
| ? | CA0025067 | • RING, STOP | 1 | SN: F30541- |
|||
| ? | CA0135020 | • RING, STOP | 1 | SN: F30541- |
|||
| ? | CA0149303 | • KIT, CLUTCH | 1 | SN: F30541- |
|||
| ? | CA0148636 | • THRUST WASHER | 1 | SN: F30541- |
|||
| ? | CA0025031 | • RING, STOP | 1 | SN: F30541- |
|||
| ? | CA0133912 | • COVER, SPRING LOCK | 1 | SN: F30541- |
|||
| ? | CA0139351 | • SPRING | 1 | SN: F30541- |
|||
| ? | CA0138984 | • SLEEVE | 1 | SN: F30541- |
|||
| ? | CA0138983 | • PISTON | 1 | SN: F30541- |
|||
| ? | CA0139199 | • SEAL | 1 | SN: F30541- |
|||
| ? | CA0139198 | • SEAL | 1 | SN: F30541- |
|||
| ? | CA0024321 | • SPRING PIN | 2 | SN: F30541- |
|||
| ? | CA0068392 | • KIT, OUTPUT SHAFT | 1 | SN: F30541- |
|||
| ? | CA0023834 | • • RIVET | 1 | SN: F30541- |
|||
| ? | CA0148565 | • • SEAL, RING | 2 | SN: F30541- |
|||
| ? | CA0139197 | • • SEAL | 1 | SN: F30541- |
|||
| ? | CA0025860 | • BEARING | 1 | SN: F30541- |
