| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (706-73-01181) | Swing Motor Assembly | 1 | SN: H52051- KIT-FLAG: _- SCC: SERIALNO: H52051- |
|||
| ? | (706-73-03511) | • Motor Sub Assembly | 1 | SN: H52051- KIT-FLAG: _- SCC: SERIALNO: H52051- |
|||
| ? | (706-73-43960) | • • Shaft, Drive | 1 | SN: H52051- KIT-FLAG: _- SCC: C2 SERIALNO: H52051- |
|||
| ? | (706-73-43880) | • • Bearing | 1 | SN: H52051- KIT-FLAG: _- SCC: C2 SERIALNO: H52051- |
|||
| ? | (706-73-43810) | • • Spacer | 1 | SN: H52051- KIT-FLAG: _- SCC: C2 SERIALNO: H52051- |
|||
| ? | (706-73-43610) | • • Spring | 2 | SN: H52051- KIT-FLAG: _- SCC: C2 SERIALNO: H52051- |
|||
| ? | (706-73-43620) | • • Seat | 1 | SN: H52051- KIT-FLAG: _- SCC: C2 SERIALNO: H52051- |
|||
| ? | (706-73-43890) | • • Bearing | 1 | SN: H52051- KIT-FLAG: _- SCC: C2 SERIALNO: H52051- |
|||
| ? | (706-73-05030) | • • Spacer Kit | 1 | SN: H52051- KIT-FLAG: _- SCC: C2 SERIALNO: H52051- |
|||
| ? | • • • Spacer, 2.1mm | 1 | SN: H52051- KIT-FLAG: _- SCC: C1 SERIALNO: H52051- |
||||
| ? | • • • Spacer, 2.4mm | 1 | SN: H52051- KIT-FLAG: _- SCC: C1 SERIALNO: H52051- |
||||
| ? | • • • Spacer, 2.7mm | 1 | SN: H52051- KIT-FLAG: _- SCC: C1 SERIALNO: H52051- |
||||
| ? | (04064-03515) | • • Ring, Snap | 1 | SN: H52051- KIT-FLAG: _- SCC: C2 SERIALNO: H52051- |
|||
| ? | 708-7T-12230 | • • Seal, Oil | 1 | SN: H52051- KIT-FLAG: _- SCC: SERIALNO: H52051- |
|||
| ? | 04065-04518 | • • Ring, Snap | 1 | SN: H52051- KIT-FLAG: _- SCC: SERIALNO: H52051- |
|||
| ? | (706-73-43190) | • • Block, Cylinder | 1 | SN: H52051- KIT-FLAG: _- SCC: C2 SERIALNO: H52051- |
|||
| ? | (706-73-43742) | • • Plate, Valve | 1 | SN: H52051- KIT-FLAG: _- SCC: C2 SERIALNO: H52051- |
|||
| ? | (720-68-19610) | • • Pin | 1 | SN: H52051- KIT-FLAG: _- SCC: C2 SERIALNO: H52051- |
|||
| ? | (706-73-43120) | • • Shaft, Center | 1 | SN: H52051- KIT-FLAG: _- SCC: C2 SERIALNO: H52051- |
|||
| ? | (706-73-43130) | • • Ring, Center | 1 | SN: H52051- KIT-FLAG: _- SCC: C2 SERIALNO: H52051- |
|||
| ? | (706-73-41110) | • • Spring | 1 | SN: H52051- KIT-FLAG: _- SCC: C2 SERIALNO: H52051- |
|||
| ? | (706-73-05020) | • • Retainer Kit | 1 | SN: H52051- KIT-FLAG: _- SCC: C2 SERIALNO: H52051- |
|||
| ? | • • • Retainer | 1 | SN: H52051- KIT-FLAG: _- SCC: C1 SERIALNO: H52051- |
||||
| ? | • • • Screw | 7 | SN: H52051- KIT-FLAG: _- SCC: C1 SERIALNO: H52051- |
||||
| ? | (706-73-43160) | • • Piston Sub Assembly | 7 | SN: H52051- KIT-FLAG: _- SCC: C2 SERIALNO: H52051- |
|||
| ? | (706-73-92340) | • • Plate | 4 | SN: H52051- KIT-FLAG: _- SCC: C2 SERIALNO: H52051- |
|||
| ? | (706-73-92350) | • • Disk | 3 | SN: H52051- KIT-FLAG: _- SCC: C2 SERIALNO: H52051- |
|||
| ? | (706-73-92380) | • • Piston, Brake | 1 | SN: H52051- KIT-FLAG: _- SCC: C2 SERIALNO: H52051- |
|||
| ? | (706-73-92390) | • • Ring, Brake | 1 | SN: H52051- KIT-FLAG: _- SCC: C2 SERIALNO: H52051- |
|||
| ? | (07000-12115) | • • O-Ring | 1 | SN: H52051- KIT-FLAG: _- SCC: C2 SERIALNO: H52051- |
|||
| ? | (07000-12130) | • • O-Ring | 2 | SN: H52051- KIT-FLAG: _- SCC: C2 SERIALNO: H52051- |
|||
| ? | (708-7T-15150) | • • Spring | 4 | SN: H52051- KIT-FLAG: _- SCC: C2 SERIALNO: H52051- |
