| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 78235-33-2001 | Camera | 1 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 2A7-06-21430 | Cover | 1 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 01010-81235 | Bolt | 2 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 01643-31232 | Washer | 2 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 22U-06-31430 | Bracket | 1 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 207-06-76460 | • Sheet | 1 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 01010-80835 | Bolt | 2 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 01643-30823 | Washer | 2 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 20Y-810-1240 | Cushion | 2 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 22U-06-31440 | Bracket | 1 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 01010-80616 | Bolt | 2 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 01643-30623 | Washer | 2 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 01010-80616 | Bolt | 3 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 01643-30623 | Washer | 3 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 175-06-81610 | Grommet | 1 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 08059-00310 | Clamp | 1 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 2A7-06-21641 | Cover | 1 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 01010-80616 | Bolt | 2 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 01643-30623 | Washer | 2 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 207-06-76451 | Cover | 1 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 2A5-06-27170 | Bracket | 1 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 2A5-06-27180 | Bracket | 1 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 01010-81225 | Bolt | 3 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 01643-31232 | Washer | 3 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 01010-81295 | Bolt | 1 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 01643-31232 | Washer | 1 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 01010-81235 | Bolt | 2 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 01643-31232 | Washer | 2 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 2A6-06-K1171 | Wiring Harness | 1 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 08034-40521 | Band | 26 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 134-03-61410 | Band | 4 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 08057-14012 | Clip | 1 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 2A5-06-26391 | Bracket | 1 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 01024-81235 | Bolt | 1 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 01643-31232 | Washer | 1 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
