| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 2A5-03-25421 | Cover Assembly | 1 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | • Cover | 1 | SN: K75001- KIT-FLAG: _- SCC: C1 SERIALNO: K75001- |
||||
| ? | 2A5-03-25411 | • Sheet | 1 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 01010-81020 | Bolt | 2 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 01643-31032 | Washer | 2 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 2A5-03-13341 | Cover Assembly | 1 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | • Cover | 1 | SN: K75001- KIT-FLAG: _- SCC: C1 SERIALNO: K75001- |
||||
| ? | 2A5-03-13371 | • Sheet | 1 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 01010-81030 | Bolt | 4 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 01643-31032 | Washer | 4 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 2A5-03-25820 | Cover | 1 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | • Cover | 1 | SN: K75001- KIT-FLAG: _- SCC: C1 SERIALNO: K75001- |
||||
| ? | 2A5-03-25810 | • Sheet | 1 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 01010-81020 | Bolt | 2 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 01643-31032 | Washer | 2 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 2A5-03-25170 | Sheet | 1 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 2A5-03-25740 | Sheet | 1 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 2A5-03-25481 | Sheet | 1 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 2A5-03-25471 | Sheet | 1 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 2A5-03-11930 | Sheet | 1 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 2A5-03-13521 | Sheet | 1 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 2A5-03-13951 | Sheet | 1 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 2A5-03-25270 | Joint | 1 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 01010-81230 | Bolt | 2 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 01643-31232 | Washer | 2 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 2A5-01-25221 | Hose Assembly | 1 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 11Y-09-11140 | Clip | 1 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 11Y-09-11140 | Clip | 1 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 2A5-979-1850 | Hose | 1 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 09479-12400 | Clip | 1 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
|||
| ? | 09479-12400 | Clip | 1 | SN: K75001- KIT-FLAG: _- SCC: SERIALNO: K75001- |
