Содержание Excavators Komatsu PC210LC-11 S/N K70001-UP(PC00015U)
Air Conditioner, Compressor Mounting (#K70001-K70324)(K013002 : K0700-001002)
Номер на схеме Каталожный номер Название Количество Детали
? 2A5-979-2511 Bracket 1
SN: K70001-K70324
KIT-FLAG: _-
SCC:
SERIALNO: K70001-K70324
? 2A5-979-1762 Bracket 1
SN: K70001-K70324
KIT-FLAG: _-
SCC:
SERIALNO: K70001-K70324
? 01010-81045 Bolt 3
SN: K70001-K70324
KIT-FLAG: _-
SCC:
SERIALNO: K70001-K70324
? 203-54-56970 Washer 3
SN: K70001-K70324
KIT-FLAG: _-
SCC:
SERIALNO: K70001-K70324
? 2A5-979-1620 Bolt 1
SN: K70001-K70324
KIT-FLAG: _-
SCC:
SERIALNO: K70001-K70324
? 01643-31445 Washer, Flat 1
SN: K70001-K70324
KIT-FLAG: _-
SCC:
SERIALNO: K70001-K70324
? 01580-11411 Nut 1
SN: K70001-K70324
KIT-FLAG: _-
SCC:
SERIALNO: K70001-K70324
? 01010-80875 Bolt 4
SN: K70001-K70324
KIT-FLAG: _-
SCC:
SERIALNO: K70001-K70324
? 01643-30823 Washer 4
SN: K70001-K70324
KIT-FLAG: _-
SCC:
SERIALNO: K70001-K70324
? 2A5-979-2521 Bracket 1
SN: K70001-K70324
KIT-FLAG: _-
SCC:
SERIALNO: K70001-K70324
? 2A5-979-2550 Bracket 1
SN: K70001-K70324
KIT-FLAG: _-
SCC:
SERIALNO: K70001-K70324
? 01010-81035 Bolt 2
SN: K70001-K70324
KIT-FLAG: _-
SCC:
SERIALNO: K70001-K70324
? 01643-31032 Washer 2
SN: K70001-K70324
KIT-FLAG: _-
SCC:
SERIALNO: K70001-K70324
? 08057-14008 Clip 1
SN: K70001-K70324
KIT-FLAG: _-
SCC:
SERIALNO: K70001-K70324
? 08193-20010 Clip 1
SN: K70001-K70324
KIT-FLAG: _-
SCC:
SERIALNO: K70001-K70324
? 01010-81025 Bolt 1
SN: K70001-K70324
KIT-FLAG: _-
SCC:
SERIALNO: K70001-K70324
? 01643-31032 Washer 1
SN: K70001-K70324
KIT-FLAG: _-
SCC:
SERIALNO: K70001-K70324
? 01010-81045 Bolt 3
SN: K70001-K70324
KIT-FLAG: _-
SCC:
SERIALNO: K70001-K70324
? 20Y-43-15410 Washer 3
SN: K70001-K70324
KIT-FLAG: _-
SCC:
SERIALNO: K70001-K70324
? 04434-50610 Clip 2
SN: K70001-K70324
KIT-FLAG: _-
SCC:
SERIALNO: K70001-K70324
? 01010-81025 Bolt 2
SN: K70001-K70324
KIT-FLAG: _-
SCC:
SERIALNO: K70001-K70324
? 01643-31032 Washer 2
SN: K70001-K70324
KIT-FLAG: _-
SCC:
SERIALNO: K70001-K70324
