Номер на схеме |
Каталожный номер |
Название |
Количество |
Детали |
|
|
|
? |
|
VALVE, MAIN CONTROL ( SEE FIG. H0120- 02A0 ) OR ( SEE FIG. H0120-03A0 ) |
|
|
|
0 |
|
? |
27224 |
VALVE ASSEMBLY, MAIN INLET PRESSURE AND RETURN SECTION |
1 |
|
|
|
|
? |
(NSS) |
• BODY |
1 |
|
|
|
|
? |
(NSS) |
• PLUG |
1 |
|
|
|
|
? |
(NSS) |
• PLUG |
1 |
|
|
|
|
? |
26407 |
• SUPPLY KIT, PILOT (BLUE) |
1 |
|
|
|
|
? |
(NSS) |
• • PLUG |
1 |
|
|
|
|
? |
(NSS) |
• • SPRING |
1 |
|
|
|
|
? |
(NSS) |
• • GUIDE, SPRING |
1 |
|
|
|
|
? |
(NSS) |
• • SEAT |
1 |
|
|
|
|
? |
(NSS) |
• • SPOOL |
1 |
|
|
|
|
? |
(NSS) |
• • BOLT |
1 |
|
|
|
|
? |
(NSS) |
• • WASHER |
1 |
|
|
|
|
? |
(NSS) |
• • SPRING |
1 |
|
|
|
|
? |
(NSS) |
• • BALL |
1 |
|
|
|
|
? |
26409 |
• VALVE, MAIN RELIEF |
1 |
|
|
|
|
? |
(NSS) |
• • SCREW, ADJUSTMENT |
1 |
|
|
|
|
? |
(NSS) |
• • NUT |
1 |
|
|
|
|
? |
(NSS) |
• • BODY, RELIEF CARTRIDGE |
1 |
|
|
|
|
? |
(NSS) |
• • O-RING |
1 |
|
|
|
|
? |
(NSS) |
• • SPOOL |
1 |
|
|
|
|
? |
(NSS) |
• • RING, BACK-UP |
1 |
|
|
|
|
? |
(NSS) |
• • O-RING |
1 |
|
|
|
|
? |
26410 |
• RELIEF KIT, DIFFERENTIAL PRESSURE |
1 |
|
|
|
|
? |
(NSS) |
• • SCREW, ADJUSTMENT |
1 |
|
|
|
|
? |
(NSS) |
• • NUT |
1 |
|
|
|
|
? |
(NSS) |
• • BODY, DIFFERENTIAL PRESSURE RELIEF |
1 |
|
|
|
|
? |
(NSS) |
• • O-RING |
1 |
|
|
|
|
? |
(NSS) |
• • SEAT, SPRING |
1 |
|
|
|
|
? |
26411 |
• • SPOOL (BLUE) |
1 |
|
|
|
|
? |
26408 |
• STRAINER, INTERNAL PILOT |
1 |
|
|
|
|
? |
(NSS) |
• • PLUG |
1 |
|
|
|
|
? |
(NSS) |
• • WASHER, SEAL |
1 |
|
|
|
|
? |
(NSS) |
• • SPRING |
1 |
|
|
|
|
? |
(NSS) |
• • RING |
1 |
|
|
|
|
? |
(NSS) |
• • FILTER |
1 |
|
|
|
|
? |
26412 |
• SPOOL KIT, COPY (BLUE) |
1 |
|
|
|
|
? |
(NSS) |
• • PLUG |
1 |
|
|
|
|
? |
(NSS) |
• • O-RING |
1 |
|
|
|
|
? |
(NSS) |
• • SPOOL |
1 |
|
|
|
