| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 28554KF | TEE, DISTRIBUTION | 1 | ||||
| ? | 10359KF | ELBOW | 1 | ||||
| ? | 11707KF | BOLT | 2 | ||||
| ? | 15528KF | WASHER, SAE FLAT | 2 | ||||
| ? | 28571KF | HOSE ASSEMBLY | 1 | ||||
| ? | 28567KF | HOSE ASSEMBLY | 1 | ||||
| ? | 11374KF | ELBOW | 1 | ||||
| ? | 28559KF | MANIFOLD, FIRE SUPPRESSION DISTRIBUTION | 1 | ||||
| ? | 4A1-921-1220 | NOZZLE | 1 | F1 | |||
| ? | 15559KF | WASHER, SAE FLAT (5/16 IN) | 4 | ||||
| ? | 10824KF | BOLT | 2 | ||||
| ? | 10395KF | ELBOW | 1 | ||||
| ? | 28560KF | MANIFOLD, FIRE SUPPRESSION DISTRIBUTION | 1 | ||||
| ? | 28564KF | HOSE ASSEMBLY | 1 | ||||
| ? | 11707KF | BOLT | 1 | ||||
| ? | 10802KF | WASHER | 1 | ||||
| ? | 4A1-62-10330 | MANIFOLD, FIRE SUPPRESSION DISTRIBUTION | 1 | ||||
| ? | 4A1-921-1230 | NOZZLE | 1 | ||||
| ? | 10788KF | NUT, NYLOCK | 2 | ||||
| ? | 10757KF | WASHER, SAE FLAT | 8 | ||||
| ? | 15568KF | BOLT | 4 | ||||
| ? | 10811KF | NUT, LOCK | 4 | ||||
| ? | 22 | ||||||
| ? | F1 - THIS PART IS AVAILABLE FROM AUTHORIZED ANSUL DISTRIBUTORS ONLY. | 23 |
