| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 11704KF | BUSHING | 4 | ||||
| ? | 12268KF | SPACER, NOSE | 1 | ||||
| ? | 18564KF | BUSHING | 2 | ||||
| ? | 85095KF | SPACER, BASE | 3 | ||||
| ? | 12270KF | CLAMP, VERMATIC | 1 | ||||
| ? | (NSS) | • BRACKET | 2 | ||||
| ? | (NSS) | • PLATE | 1 | ||||
| ? | (NSS) | • BOLT | 3 | ||||
| ? | 16513KF | TUBE KIT | 3 | ||||
| ? | 15117KF | • CONNECTOR, STR | 6 | ||||
| ? | 16507KF | TUBE KIT | 2 | ||||
| ? | 15152KF | • CONNECTOR, STR | 4 | ||||
| ? | 16506KF | TUBE KIT | 4 | ||||
| ? | 15225KF | • CONNECTOR, STRAIGHT | 8 | ||||
| ? | 10771KF | WASHER, SAE FLAT | 9 | ||||
| ? | 15517KF | BOLT | 3 | ||||
| ? | 10719KF | BOLT | 6 | ||||
| ? | 15236KF | CLAMP, SADDLE TOP TUBE | 6 | ||||
| ? | 15272KF | CLAMP, SADDLE TOP TUBE | 3 | ||||
| ? | 23222KF | CLAMP, SADDLE TOP TUBE | 3 | ||||
| ? | 12447KF | CLAMP | 3 | ||||
| ? | DEFLECTOR, TREE ( SEE FIG. T2000-01A0 ) |
