| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 26140KF | SEAT ASSEMBLY, STANDARD OPERATORS | 1 | ||||
| ? | 22058 | • COVER | 1 | ||||
| ? | 22059 | • PAD KIT, ARM | 1 | ||||
| ? | 22060 | • PAD, L.H. ARM REST | 1 | ||||
| ? | 22062 | • KNOB, FRONT ARM ADJUSTMENT | 2 | ||||
| ? | 22063 | • KNOB, RECLINER | 1 | ||||
| ? | 22064 | • CUSHION, SEAT | 1 | ||||
| ? | 22065 | • SKIRT, SEAT | 1 | ||||
| ? | 22066 | • KNOB, CONTROL CARRIAGE LOCK | 2 | ||||
| ? | 22051 | • CARRIAGE, CONTROL | 1 | ||||
| ? | 22067 | • SPRING, GAS | 2 | ||||
| ? | 19254 | • BRACKET, JOYSTICK MOUNTING | 2 | ||||
| ? | 22068 | • SCREW, MACHINE | 8 | ||||
| ? | 22069 | • NUT, SPEED | 8 | ||||
| ? | 22070 | • KNOB, LUMBAR SUPPORT ADJUSTMENT | 1 | ||||
| ? | 22061 | • PAD, R.H. ARM REST | 1 | ||||
| ? | 22071 | • SKIRT, L.H. JOYSTICK MOUNT | 1 | ||||
| ? | 22072 | • SKIRT, R.H. JOYSTICK MOUNT | 1 |
