| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | VALVE, MAIN CONTROL ( SEE FIG. H0120- 02A0 ) OR ( SEE FIG. H0120-03A0 ) | 0 | |||||
| ? | VALVE, SWING FUNCTION ( SEE FIG. H0120- 10A0 ) | ||||||
| ? | OR | 2 | |||||
| ? | VALVE, L90 ( SEE FIG. H0120-11A0 ) | ||||||
| ? | OR | 4 | |||||
| ? | VALVE, ACCUMULATOR/LATERAL TILT/CLAMP FUNCTION ( SEE FIG. H0120-12A0 ) | ||||||
| ? | OR | 6 | |||||
| ? | VALVE, CAB LEVELER FUNCTION ( SEE FIG. H0120-13A0 ) | ||||||
| ? | 23414 | • END CAP KIT, A-SIDE | 1 | ||||
| ? | (NSS) | • • BLOCK | 1 | ||||
| ? | (NSS) | • • BOLT | 3 | ||||
| ? | (NSS) | • • SEAL | 1 | ||||
| ? | (NSS) | • • SCREW | 1 | ||||
| ? | 15412KF | • PLUG | 1 | ||||
| ? | 26561 | • NUT, SEAL | 1 | ||||
| ? | 10412749 | • SEAL KIT, A-SIDE | 1 | ||||
| ? | (NSS) | • • SEAL | 1 | ||||
| ? | (NSS) | • • SEAL | 1 |
