| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | TANK, HYDRAULIC ( SEE FIG. H0110-01A2 ) | ||||||
| ? | 23598KF | GUARD, RETURN FILTER | 1 | ||||
| ? | 22888KF | BOLT | 5 | ||||
| ? | 15534KF | WASHER, SAE FLAT | 12 | ||||
| ? | 10815KF | NUT, LOCK | 7 | ||||
| ? | 27825KF | COVER, HYDRAULIC TANK DEBRIS | 1 | ||||
| ? | 27399KF | PLATE, FILTER GUARD COVER | 1 | ||||
| ? | 10757KF | WASHER, SAE FLAT (1/4) | 4 | ||||
| ? | 10736KF | BOLT | 2 | ||||
| ? | 15502KF | BOLT | 2 | ||||
| ? | 10805KF | WASHER, SAE FLAT | 2 | ||||
| ? | 15528KF | WASHER, SAE FLAT | 9 | ||||
| ? | 15542KF | BOLT | 9 | ||||
| ? | 15604KF | BOLT | 4 | ||||
| ? | 10739KF | BOLT | 1 | ||||
| ? | 4A1-46-10880 | SUPPORT, HYDRAULIC TANK | 1 | ||||
| ? | 4A1-54-11820 | • BRACKET | 1 | ||||
| ? | 4A1-46-10850 | • SEAT | 1 | ||||
| ? | 4A1-46-10830 | • PLATE, TOP | 1 | ||||
| ? | 4A1-46-10820 | • PLATE, CHANNEL | 1 | ||||
| ? | 4A1-46-10810 | • PLATE, BASE | 1 | ||||
| ? | 12270KF | • CLAMP, TUBE | 1 | ||||
| ? | 01580-01008 | • NUT | 2 | ||||
| ? | 01580-00605 | • NUT | 4 | ||||
| ? | 01573-12306 | • SEAT | 2 | ||||
| ? | 83915KF | SHIM, TANK SUPPORT (1/4 IN) | A/R | ||||
| ? | 83914KF | SHIM, TANK SUPPORT (1/8 IN) | A/R |
