| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | PUMP, R.H. TRACK DRIVE ( SEE FIG. H0242- 01A0 ) | ||||||
| ? | 17738KF | PROTECTION, HOSE GUARD | 1 | ||||
| ? | 4A1-62-20520 | HOSE | 1 | ||||
| ? | 4A1-62-10770 | ELBOW, 45 DEGREE SWIVEL | 1 | ||||
| ? | 4A1-62-10760 | ELBOW, 90 DEGREE | 3 | ||||
| ? | 08034-20823 | BAND, TIE | 1 | ||||
| ? | 4A1-62-20580 | HOSE | 1 | ||||
| ? | 4A1-62-20590 | HOSE | 1 | ||||
| ? | 4A1-62-10780 | CONNECTOR, STR | 1 | ||||
| ? | 4A1-62-20510 | HOSE | 1 | ||||
| ? | MANIFOLD, ROTARY ( SEE FIG. H0270-01A0 ) | ||||||
| ? | 4A1-62-10790 | CONNECTOR | 2 | ||||
| ? | 4A1-62-10750 | CONNECTOR, STR BULKHEAD | 2 | ||||
| ? | (NSS) | • NUT | 1 | ||||
| ? | BRACKET, BULKHEAD ( SEE FIG. R0050-01A0 ) |
