Содержание Forestry Komatsu XT430L-3 S/N A2101-UP(XT430L-3)
H1002-01A0 HYDRAULIC PIPING PILOT PRESSURE MANIFOLD TO HYDRAULIC TANK(H-164 : H1002-01A0)
Номер на схеме Каталожный номер Название Количество Детали
? MANIFOLD, PILOT PRESSURE ( SEE FIG. H0318-01A0 )
? ELBOW, 90 DEGREE ( SEE FIG. H0318-01A1 )
? 20566KF HOSE ASSEMBLY 1
? 15258KF CONNECTOR, STR 1
