| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | GEAR BOX, TRIPLE PUMP DRIVE ( SEE FIG. H0240-01A0 ) | ||||||
| ? | 15842KF | FILTER, IMPLEMENT SCREEN | 1 | ||||
| ? | 15448KF | O-RING | 1 | ||||
| ? | 22462KF | PLATE, INTERMEDIATE SUCTION PORT | 1 | ||||
| ? | 22441KF | VALVE, BUTTERFLY SHUT OFF | 1 | ||||
| ? | 23095KF | BOLT | 4 | ||||
| ? | 22639KF | FLANGE KIT, SPLIT | 1 | ||||
| ? | (NSS) | • FLANGE | 2 | ||||
| ? | 18695KF | • O-RING | 1 | ||||
| ? | (NSS) | • BOLT | 4 | ||||
| ? | (NSS) | • WASHER | 4 | ||||
| ? | 27767KF | TUBE | 1 | ||||
| ? | 15574KF | BUSHING, REDUCER | 1 | ||||
| ? | 22302KF | VALVE, PROBALYSER | 1 | F1 | |||
| ? | 27909KF | CLAMP, CONSTANT TORQUE | 2 | ||||
| ? | 27894KF | HOSE, SUCTION (1010-48) | 1 | ||||
| ? | 27769KF | TUBE, SUCTION | 1 | ||||
| ? | 18306KF | FLANGE KIT, SPLIT | 1 | ||||
| ? | 15502KF | • BOLT | 1 | ||||
| ? | 10771KF | • WASHER, SAE FLAT | 4 | ||||
| ? | (NSS) | • FLANGE | 1 | ||||
| ? | 18695KF | • O-RING | 1 | ||||
| ? | 10776KF | NUT, HEX | 4 | ||||
| ? | 15550KF | WASHER, SAE FLAT | 4 | ||||
| ? | 15442KF | O-RING | 1 | ||||
| ? | PUMP, IMPLEMENT ( SEE FIG. H0301-02A0 ) | ||||||
| ? | 26 | ||||||
| ? | F1 - USED TO TAKE OIL SAMPLES. | 27 |
