| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | VALVE, MAIN CONTROL ( SEE FIG. H0120- 02A0 ) OR ( SEE FIG. H0120-03A0 ) | 0 | |||||
| ? | 27266 | VALVE ASSEMBLY, MAIN BOOM | 1 | ||||
| ? | 26421 | • PLUG, ORIFICE | 1 | ||||
| ? | 27232 | • COMPENSATOR | 1 | ||||
| ? | 26428 | • PC KIT, SPRING | 1 | ||||
| ? | 26431 | • SPOOL, VOAC/K220 | 1 | ||||
| ? | 26559 | • WASHER, SEAL | 1 | ||||
| ? | 26550 | • BOLT, SPOOL | 1 | ||||
| ? | 26422 | • PLUG, COMPENSATOR | 1 | ||||
| ? | • END CAP, A SIDE SECTION ( SEE FIG. H0120-20A0 ) | ||||||
| ? | 26418 | • SEAL KIT, EC A SIDE | 1 | ||||
| ? | 26425 | • PORT RELIEF, K220 | 1 | ||||
| ? | 26426KF | • PLUG, PORT RELIEF | 1 | ||||
| ? | • END CAP, B SIDE SECTION ( SEE FIG. H0120-20A0 ) | ||||||
| ? | • SEAL KIT, PC B SIDE ( SEE FIG. H0120- 20A0 ) | ||||||
| ? | (NSS) | • PLUG | 1 | ||||
| ? | (NSS) | • PLUG, ORIFICE | 1 |
