| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 6217-51-5103 | HEAD ASSEMBLY | 1 | ||||
| ? | (NSS) | • HEAD | 1 | ||||
| ? | 600-211-1890 | • SPRING | 1 | ||||
| ? | 6162-55-5230 | • VALVE | 1 | ||||
| ? | 6162-53-5430 | • PACKING | 1 | ||||
| ? | 6217-51-5660 | • CAP | 1 | ||||
| ? | 600-211-1340 | CARTRIDGE, OIL FILTER | 1 | ||||
| ? | 01010-81065 | BOLT | 2 | ||||
| ? | 01643-31032 | WASHER | 2 | ||||
| ? | 01011-81015 | BOLT | 2 | ||||
| ? | 01643-31032 | WASHER | 2 | ||||
| ? | 6251-51-5110 | BRACKET | 1 | ||||
| ? | 01011-81085 | BOLT | 2 | ||||
| ? | 01643-31032 | WASHER | 2 | ||||
| ? | 421-06-62251 | BRACKET | 1 | ||||
| ? | 01010-81025 | BOLT | 2 | ||||
| ? | 01643-31032 | WASHER | 2 |
