| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 6150-21-5550 | PAN, OIL | 1 | ||||
| ? | 6150-21-5813 | GASKET | 1 | ||||
| ? | 01435-01025 | BOLT | 36 | ||||
| ? | 421-01-41271 | HOSE ASSEMBLY | 1 | ||||
| ? | 421-01-41281 | • ELBOW ASSEMBLY | 1 | ||||
| ? | 421-01-41290 | • HOSE ASSEMBLY | 1 | ||||
| ? | 07281-00359 | • CLAMP, HOSE | 1 | ||||
| ? | 07002-23634 | O-RING | 1 | ||||
| ? | 08034-00519 | BAND | 1 | ||||
| ? | 6207-21-5340 | GAUGE | 1 | ||||
| ? | 6252-21-5130 | GUIDE | 1 | ||||
| ? | 6150-21-5920 | COLLAR | 1 | ||||
| ? | 6150-21-5930 | NUT | 1 | ||||
| ? | 6252-21-5140 | BRACKET | 1 | ||||
| ? | 01010-81025 | BOLT | 1 | ||||
| ? | 01643-31032 | WASHER | 1 | ||||
| ? | 04434-51310 | CLIP | 1 | ||||
| ? | 01010-81025 | BOLT | 1 | ||||
| ? | 01643-31032 | WASHER | 1 | ||||
| ? | 6741-81-9220 | SWITCH, LEVEL | 1 | ||||
| ? | 7861-91-4220 | • O-RING | 1 | ||||
| ? | 01435-00612 | BOLT | 3 | ||||
| ? | 6672-12-6290 | PLUG | 1 | ||||
| ? | 07005-01612 | SEAL, WASHER | 1 | ||||
| ? | 6150-51-6330 | STRAINER | 1 | ||||
| ? | 07000-73045 | O-RING | 1 | ||||
| ? | 01010-81035 | BOLT | 2 | ||||
| ? | 6150-51-6340 | BRACKET | 1 | ||||
| ? | 01010-81020 | BOLT | 1 | ||||
| ? | 01643-31032 | WASHER | 1 | ||||
| ? | 01010-81030 | BOLT | 1 | ||||
| ? | 01643-31032 | WASHER | 1 | ||||
| ? | 01580-01008 | NUT | 1 | ||||
| ? | 01643-31032 | WASHER | 1 |
