| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 07020-00000 | GREASE FITTING (STRAIGHT) | 4 | ||||
| ? | 205-70-51390 | CONNECTOR, STR BULKHEAD 2238-2-4S | 4 | ||||
| ? | 206-958-1380 | HOSE, STICK BOOM PIVOT R.H. | 1 | ||||
| ? | 206-958-1390 | HOSE, STICK BOOM PIVOT L.H. | 1 | ||||
| ? | 206-958-1410 | HOSE, HEEL CYLINDER ROD | 1 | ||||
| ? | 206-958-1410 | HOSE, ARM CYLINDER BASE | 1 | ||||
| ? | 20F-70-16190 | ELBOW | 2 | ||||
| ? | 205-70-51390 | NIPPLE, GREASE | 1 | ||||
| ? | 20F-70-16190 | ELBOW | 1 | ||||
| ? | 04434-51212 | CLIP | 12 | ||||
| ? | 01010-81230 | BOLT | 3 | ||||
| ? | 01643-31232 | WASHER | 3 | ||||
| ? | 04434-51212 | CLIP | 4 | ||||
| ? | 01010-81230 | BOLT | 2 | ||||
| ? | 01643-31232 | WASHER | 2 | ||||
| ? | 04434-51212 | CLIP | 4 | ||||
| ? | 01010-81225 | BOLT | 2 | ||||
| ? | 01643-31232 | WASHER | 2 | ||||
| ? | 04434-51212 | CLIP | 1 | ||||
| ? | 01010-81225 | BOLT | 1 | ||||
| ? | 01643-31232 | WASHER | 1 |
