| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 703-08-33672 | SWIVEL JOINT ASSEMBLY | 1 | ||||
| ? | 703-08-33631 | • SWIVEL JOINT ASSEMBLY | 1 | ||||
| ? | (NSS) | • • ROTOR | 1 | ||||
| ? | 703-08-95620 | • • SEAL | 6 | ||||
| ? | 07000-15080 | • • O-RING | 2 | ||||
| ? | 703-08-93771 | • • COVER | 1 | ||||
| ? | (NSS) | • • SHAFT | 1 | ||||
| ? | 703-13-98930 | • • PLUG | 1 | ||||
| ? | 703-08-95770 | • • SEAL, DUST | 1 | ||||
| ? | 703-08-94510 | • • RING | 1 | ||||
| ? | 04064-07525 | • • RING, SNAP, FOR SHAFT SIDE | 1 | ||||
| ? | 703-08-93170 | • • COVER | 1 | ||||
| ? | 07000-12105 | • • O-RING | 1 | ||||
| ? | 01010-80835 | • • BOLT | 4 | ||||
| ? | 01643-30823 | • • WASHER | 4 | ||||
| ? | 02782-10628 | • ELBOW | 4 | ||||
| ? | 07002-12434 | • O-RING | 4 | ||||
| ? | 02782-10522 | • ELBOW | 1 | ||||
| ? | 07002-12434 | • O-RING | 1 | ||||
| ? | 11Y-62-12160 | • ELBOW | 1 | ||||
| ? | 07002-11423 | • O-RING | 1 | ||||
| ? | 21W-62-42630 | • TEE | 1 | ||||
| ? | 07002-11423 | • O-RING | 1 | ||||
| ? | 07371-30640 | • FLANGE, SPLIT | 8 | ||||
| ? | 707-88-33030 | • CAP | 4 | ||||
| ? | 07372-21035 | • BOLT | 16 | ||||
| ? | 01643-51032 | • WASHER | 16 |
