| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 207-06-A1530 | PUMP ASSEMBLY | 1 | ||||
| ? | 207-06-A2010 | • BLOCK | 1 | ||||
| ? | 207-06-A2020 | • PUMP | 1 | ||||
| ? | 207-06-A2030 | • DOWEL PIN | 2 | ||||
| ? | 207-06-A2040 | • SUCTION TUBE | 1 | ||||
| ? | 207-06-A2050 | • FILTER SCREEN | 1 | ||||
| ? | 207-06-A2060 | • RETURN TUBE | 1 | ||||
| ? | 207-06-A2070 | • RETURN TUBE 90 DEGREE | 1 | ||||
| ? | 207-06-A2080 | • CARTRIDGE | 1 | ||||
| ? | 207-06-A2090 | • VALVE ASSEMBLY | 1 | ||||
| ? | 207-06-A2330 | • SHAFT | 1 | ||||
| ? | 207-06-A2340 | • SCREW | 2 | ||||
| ? | 207-06-A2320 | • RESERVOIR | 1 | ||||
| ? | 207-06-A2140 | • CLAMP | 1 | ||||
| ? | 207-06-A2150 | • PLUG | 1 | ||||
| ? | 207-06-A2160 | • BRACKET | 1 | ||||
| ? | 207-06-A2170 | • SCREW | 2 | ||||
| ? | 207-06-A2180 | • WASHER | 2 | ||||
| ? | 207-06-A2190 | • SWITCH | 1 | ||||
| ? | 207-06-A2210 | • CABLE | 1 | ||||
| ? | 207-06-A2220 | • WIRE ASSEMBLY | 1 | ||||
| ? | 207-06-A2230 | • WIRING HARNESS | 1 | ||||
| ? | 207-06-A1432 | • SWITCH, TILT | 1 | ||||
| ? | 207-06-A2250 | • BOOT, 4 GA | 4 | ||||
| ? | 207-06-A2260 | • BOOT, 16 GA | 1 | ||||
| ? | 207-06-A2270 | • MOTOR 24 V DC | 1 | ||||
| ? | 207-06-A2280 | • SCREW | 4 | ||||
| ? | 207-06-A2290 | • CARTRIDGE | 1 | ||||
| ? | 207-06-A2310 | • POPPET | 1 |
