| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 2A5-43-11142 | ARMREST, L.H. | 1 | ||||
| ? | 2A5-43-11712 | SHAFT | 1 | ||||
| ? | 2A5-43-11790 | KNOB, ANGLE ADJUSTMENT | 1 | ||||
| ? | 702-16-72510 | PIN | 1 | ||||
| ? | 2A5-43-11831 | COVER | 1 | ||||
| ? | 01370-40510 | SCREW | 3 | ||||
| ? | 01641-50508 | WASHER, FLAT | 3 | ||||
| ? | 2A5-43-11112 | BRACKET | 1 | ||||
| ? | 2A5-43-11811 | PIN | 1 | ||||
| ? | 01010-80616 | BOLT | 1 | ||||
| ? | 01643-30623 | WASHER | 1 | ||||
| ? | 2A5-43-11821 | SPRING | 1 | ||||
| ? | 2A5-43-12382 | PLATE | 2 | ||||
| ? | 2A5-43-12391 | PLATE | 1 | ||||
| ? | 01010-D0612 | BOLT | 2 | ||||
| ? | 01643-70623 | WASHER | 2 | ||||
| ? | 01010-D0620 | BOLT | 2 | ||||
| ? | 01643-70623 | WASHER | 2 | ||||
| ? | 2A5-43-11842 | COVER | 1 | ||||
| ? | 01023-20512 | SCREW | 2 | ||||
| ? | 01026-A0825 | BOLT | 2 | ||||
| ? | 20Y-43-41181 | CAP | 1 | ||||
| ? | 01023-20512 | SCREW | 1 |
