| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | WB0430 | FITTING, BULKHEAD - STRAIGHT | 2 | ||||
| ? | TF2449 | FLAT WASHER - 3/4" | 8 | ||||
| ? | WB0584 | FITTING, STRAIGHT | 4 | ||||
| ? | WB0593 | FITTING, STRAIGHT | 1 | ||||
| ? | WB0585 | FITTING, STRAIGHT | 2 | ||||
| ? | SR6301 | CAPSCREW - 1/4" - 20NC X 2 3/4" | 2 | ||||
| ? | C5774 | LOCKWASHER - 1/4" | 2 | ||||
| ? | C5780 | NUT - 1/4" - 20NC | 2 | ||||
| ? | VN9773 | FLAT WASHER - 1/4" | 4 | ||||
| ? | H8136 | CAPSCREW - 1/4" - 20NC X 1/2" | 2 | ||||
| ? | WB0249 | FITTING, ELBOW - 45 DEG | 2 | ||||
| ? | VC1387 | CAPSCREW - 1/2" - 13NC X 1" | 5 | ||||
| ? | VC7836 | FLAT WASHER - 1/2" | 10 | ||||
| ? | TR5445 | LOCKWASHER - 1/2" | 5 | ||||
| ? | TR6643 | NUT - 1/2" - 13NC | 5 | ||||
| ? | SG2103 | GROMMET, RUBBER | 1 | ||||
| ? | WB0537 | FITTING, ELBOW - 45 DEG | 1 | ||||
| ? | WB0581 | FITTING, STRAIGHT | 1 | ||||
| ? | WB0574 | FITTING, STRAIGHT | 1 | ||||
| ? | C1602 | CAPSCREW - 3/8" - 16NC X 1" | 4 | ||||
| ? | DF3042 | FLAT WASHER - 3/8" | 4 |
