| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | XB3684 | SHIELD | 1 | ||||
| ? | XB3682 | SHIELD | 1 | ||||
| ? | MM0605 | CAPSCREW - M10 X 1.50 X 25 | 16 | ||||
| ? | MM0471 | LOCKWASHER - M10 | 16 | ||||
| ? | MM0461 | FLAT WASHER - M10 | 20 | ||||
| ? | XB3673 | BRACKET | 1 | ||||
| ? | XB3677 | SHIELD | 1 | ||||
| ? | XB3674 | BRACKET | 1 | ||||
| ? | XB3678 | SHIELD | 1 | ||||
| ? | XB3681 | SHIELD | 1 | ||||
| ? | MM0693 | LOCKNUT - M10 X 1.50 | 4 | ||||
| ? | WB3092 | CLAMP, CUSHIONED - 7/8" | 11 | ||||
| ? | WB3096 | CLAMP, CUSHIONED - 1 1/4" | 1 | ||||
| ? | WB1300 | CLAMP, CUSHIONED - 5/8" | 1 | ||||
| ? | WB1303 | CLAMP, CUSHIONED - 3/4" | 1 | ||||
| ? | TY8375 | SPACER | 8 | ||||
| ? | XB3665 | SPACER | 1 | ||||
| ? | XB3667 | PLATE | 1 | ||||
| ? | MM0047 | CAPSCREW - M10 X 1.50 X 30 | 2 | ||||
| ? | MM0178 | NUT - M10 X 1.50 | 2 | ||||
| ? | 01584-01008 | NUT, FLANGED | 4 |
