| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | VE5667 | HOUSING | 2 | ||||
| ? | VE8095 | PLUG | 8 | ||||
| ? | VE7830 | PIN, ROLL | 4 | ||||
| ? | VE9286 | SEAL, O-RING (1)/(4) | 4 | ||||
| ? | VE7731 | RING, BACKUP (1)/(4) | 4 | ||||
| ? | VE7831 | PISTON ASSEMBLY (3)/(4) | 4 | ||||
| ? | • PISTON (6) | 4 | |||||
| ? | VJ7237 | • RING, THREADED | 4 | ||||
| ? | VJ7238 | • WASHER | 4 | ||||
| ? | VJ7240 | • PIN, ADJUSTER | 8 | ||||
| ? | VE5668 | • PIN, RETURN | 4 | ||||
| ? | VJ5758 | • SPRING, ADJUSTER | 4 | ||||
| ? | VJ7233 | • GUIDE, INNER | 4 | ||||
| ? | VJ7234 | • SPRING, OUTER | 4 | ||||
| ? | VJ7235 | • RING, RETAINING | 4 | ||||
| ? | VJ7236 | • RING, LOCK | 4 | ||||
| ? | VE9287 | • SEAL, O-RING | 4 | ||||
| ? | VE7829 | LOCKWASHER (3)/(4) | 4 | ||||
| ? | VN9951 | LOCKNUT - 5/16" - 18NC (3)/(4) | 4 | ||||
| ? | TR6102 | SCREW, BLEEDER (4) | 5 | ||||
| ? | VJ5753 | SHIELD, DUST (1)/(4) | 4 | ||||
| ? | VE3909 | LINING ASSEMBLY (2)/(4) | 2 | ||||
| ? | VJ7242 | PLATE | 2 | ||||
| ? | VJ7241 | PLATE | 2 | ||||
| ? | VE7836 | CAPSCREW | 8 | ||||
| ? | TUBE (5)/(6) | 1 | |||||
| ? | FITTING, ELBOW (5)/(6) | 2 | |||||
| ? | VE9284 | NOTE: (1) INCLUDED IN VE9284 SEAL KIT. | |||||
| ? | VE9285 | (2) INCLUDED IN VE9285 LINING KIT. | |||||
| ? | VE4023 | (3) INCLUDED IN VE4023 HARDWARE KIT. | |||||
| ? | VE9283 | (4) INCLUDED IN VE9283 REBUILD KIT. | |||||
| ? | AK7499 | (5) INCLUDED IN AK7499 TUBING KIT. | |||||
| ? | (6) NOT SERVICED SEPARATELY. |
