| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | VE5188 | FLAT WASHER | 24 | ||||
| ? | VE4743 | PLUG, PIPE | 6 | ||||
| ? | VE4234 | CAP, BEARING | 1 | ||||
| ? | VE4745 | SCREW | 24 | ||||
| ? | VE4746 | SEAL RING | 1 | ||||
| ? | VE4500 | CAPSCREW | 12 | ||||
| ? | VE3027 | WASHER | 30 | ||||
| ? | VE2466 | THRUST RING | 1 | ||||
| ? | VE0663 | SHIM SET | 1 | ||||
| ? | VE4501 | SHIM | 20 | ||||
| ? | VE4502 | SHIM | 16 | ||||
| ? | VE4503 | SHIM | 20 | ||||
| ? | VE4504 | SHIM | 5 | ||||
| ? | VE4505 | SHIM | 4 | ||||
| ? | VE0517 | SEAL | 1 | ||||
| ? | BF2111 | MOTOR | 1 | ||||
| ? | VE0667 | CAPSCREW | 9 | ||||
| ? | VE4696 | LOCKWASHER - 5/16" | 4 | ||||
| ? | VS8330 | SCREW | 4 | ||||
| ? | VE4785 | RING, ADAPTER | 1 | ||||
| ? | VE4784 | WASHER | 10 | ||||
| ? | VE4473 | BOLT, HEX HEAD | 1 | ||||
| ? | PB8889 | BRAKE HUB | 1 | ||||
| ? | VE0755 | END PLATE | 1 | ||||
| ? | VE4361 | CABLE TIE | |||||
| ? | BF1218 | TYRAP | |||||
| ? | VE0715 | WHEEL COVER | 1 | ||||
| ? | BF3864 | LATCH | 4 | ||||
| ? | VE3643 | BALL | 4 | ||||
| ? | VE4546 | SCREW, SOCKET HEX HEAD | 8 | ||||
| ? | VE0499 | BEARING, OUTBOARD | 1 | ||||
| ? | VE4499 | CAPSCREW | 10 | ||||
| ? | VJ0972 | MAGNETIC, PICKUP | 1 | ||||
| ? | VE0662 | WEAR BAND | 3 | ||||
| ? | VE4785 | RING, ADAPTER | 1 | ||||
| ? | VE4470 | INSULATION | |||||
| ? | VE4335 | TAPE, FIBERGLASS - 1" WIDE | |||||
| ? | VE3915 | VARNISH/GALLON | |||||
| ? | VE4783 | PUTTY, SILASTIC | |||||
| ? | VE4742 | HUB, WHEEL | 1 | ||||
| ? | AK3653 | BRUSH, CARBON | 12 |
