| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | PB4252 | PANEL, ISO AMP | 1 | ||||
| ? | VE4688 | CHANNEL | 2 | ||||
| ? | VE4689 | MACHINE SCREW - #10 - 32NF X 3/4" | 4 | ||||
| ? | VS6662 | FLAT WASHER - #10 | 8 | ||||
| ? | SG7707 | LOCKWASHER - #10 | 4 | ||||
| ? | TR5445 | LOCKWASHER - 1/2" | 8 | ||||
| ? | VE2269 | LOCKWASHER - #10 | 4 | ||||
| ? | VE3615 | MODULE | 1 | ||||
| ? | BF0682 | RESISTOR - 1/4 WATT, 150,000 OHM | 1 | ||||
| ? | VE1110 | RESISTOR - 1/4 WATT, 1020 OHM | 1 | ||||
| ? | VE1107 | RESISTOR - 1/4 WATT, 221 OHM | 1 | ||||
| ? | VE1122 | RESISTOR - 1/4 WATT, 13,300 OHM | 1 | ||||
| ? | VE1114 | RESISTOR - 1/4 WATT, 2870 OHM | 1 | ||||
| ? | VS6593 | RESISTOR - 1/8 WATT, (SEL RESISTANCE VALUE AT TEST) | 2 | ||||
| ? | VP9545 | RESISTOR | 1 | ||||
| ? | VS7211 | CAPACITOR - 1 MFD, 50 VOLT | 2 | ||||
| ? | VS7593 | CAPACITOR - 0.01 MFD, 100 VOLT | 1 | ||||
| ? | VS7521 | AMPLIFIER | 1 | ||||
| ? | VE5089 | INTEGRATED CIRCUIT MODULE | 1 | ||||
| ? | VE2598 | TERMINAL | 4 | ||||
| ? | VP9596 | MACHINE SCREW - #4 - 40NC X 1/4" | 2 | ||||
| ? | VE4691 | LOCKWASHER - #4 | 2 | ||||
| ? | VP9537 | WELD SCREW - #10 - 32NF X 15/16" | 7 | ||||
| ? | VE4692 | NUT | 7 | ||||
| ? | VE4693 | LOCKWASHER - #10 (INTERNAL TOOTH) | 7 | ||||
| ? | VP9546 | RESISTOR | 2 |
