| Наименование | Страница | Код страницы |
|---|---|---|
| HOIST PUMP ASSEMBLY PB9668 | 424 | 55006 |
| ALTERNATOR - 22M2 1/7 PC2665 | 636 | 64357 |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | PC2665 | ALTERNATOR/BLOWER ASSEMBLY (SEE INDEX) | 1 | 64357 | |||
| ? | SG7814 | CAPSCREW - 3/8" - 24NF X 1 1/4" | 8 | ||||
| ? | (NOT USED IN THIS APPLICATION) | ||||||
| ? | PC0184 | DRIVE SHAFT ASSEMBLY | 1 | ||||
| ? | VE3436 | • FLANGE | 2 | ||||
| ? | VE3438 | • CROSS ASSEMBLY (1) | 2 | ||||
| ? | VE3437 | • CROSS, BEARING | 8 | ||||
| ? | VE3439 | • RING, RETAINING (1) | 8 | ||||
| ? | • • CAP, BEARING (NOT SERVICED SEPARATELY) (1) | 8 | |||||
| ? | 70653 | • YOKE ASSEMBLY | 1 | ||||
| ? | TH7435 | • FITTING, GREASE (1) | 2 | ||||
| ? | 70657 | • CAP (2) | 1 | ||||
| ? | 70655 | • RETAINER (2) | 1 | ||||
| ? | 53890V | • WASHER (2) | 1 | ||||
| ? | VN9037 | CAPSCREW - 3/8" - 16NC X 1 1/4" | 8 | ||||
| ? | WA0386 | NUT - 3/8" - 16NC | 8 | ||||
| ? | PB7940 | FLANGE, COMPANION | 1 | ||||
| ? | PB9668 | HOIST PUMP ASSEMBLY (SEE INDEX) | 1 | 55006 | |||
| ? | VE7350 | NOTE: (1) INCLUDED IN VE7350 CROSS & BEARING KIT. | |||||
| ? | 1216225H1 | (2) INCLUDED IN 1216225H1 DUST CAP KIT. |
